Image Sensor

1/2.8” Progressive Scan CMOS

Max Resolution

2592(H) × 1944(V)

Shutter Speed

1/5 to 1/20,000s

Min Illumination

Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON)

Day & Night

Auto (ICR)

S/N Ratio

55 dB

Focal Length

5.3 to 79.5 mm

Max. Aperture

F1.6 to F2.8

Field of View (FOV)

H: 56.2° to 4.5°, V: 42.3° to 3.3°

Optical Zoom

15x

Digital Zoom

16x

Iris

Auto/Manual

Focus Control

Auto/Manual/Semi-automatic

Multi-Object Detection

- Supports face, human, and vehicle detection & capture
- Supports human and vehicle attribute detection
- Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest
Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion detection, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection
- Supports accurate target classification (human/vehicle)

Smoke and Flame Detection

Supported

People Counting

Supported

Number of Streams

3 Streams

Resolution

Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720
Stream2: D1, VGA, CIF
Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 kbps to 12 Mbps
Stream2: 100 kbps to 6 Mbps
Stream3: 100 kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Supported

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor, Mirror

Exposure Mode

Auto, Manual, Shutter priority, Iris priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

HLC, BLC, Defog, WDR, Anti-shake

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

Support 40 zones, mask color configurable

Pan/Tilt Range

Pan: 0° to 355° endless, Tilt: 0° to +90° (auto-flip)

Pan Speed

Pan speed: 0.1° to 200°/s, preset speed: 200°/s

Tilt Speed

Tilt speed: 0.1° to 160°/s, preset speed: 160°/s

Preset Accuracy

≤ 0.2°

Preset

300

Track

6 Track

Scan

12 Scan

Tour

12 Tour (up to 32 presets each tour)

Intelligent Tracking

Supported
Object auto tracking (Person/Vehicle)

Power-Off Memory

Supported

3D Positioning

Supported

PTZ Status Display

Supported

Idle Motion

The time can be set (1-240 minutes), and functions such as preset positions, patrols, scans, and tracks can be run.

Alarm Triggers

IVS, Motion detection, Network alarm, Disk alarm, Day/Night switch alarm

Event Actions

Alarm record, FTP upload, SMTP upload, Linkage tracking

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X(EAP-TLS)

Secure Communication

HTTPS, WSS(WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt(AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

SD Card Slot

Built-in microSD card slot, up to 256GB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / PoE (802.3af)

Power Consumption

Less than 12W

Operating Temperature

-20°C to 50°C (-4°F to 122 °F)

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
CE-LVD
- EN IEC 62368-1
FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, bubble: plastic

Dimensions

φ143.5 × 130.6 mm (φ5.65 × 5.14 inch)

Net Weight

1.15 Kg (2.54 lb)

Detect

104 to 1,560 m (341.21 to 5,118.11 ft)

Observe

41.6 to 624 m (136.48 to 2,047.24 ft)

Recognize

20.8 to 312 m (68.24 to 1,023.62 ft)

Identify

10.4 to 156 m (34.12 to 511.81 ft)
