Camera |
|
Image Sensor |
1/1.8” Progressive Scan CMOS |
|
Max. Resolution |
8MP, 3840(H) × 2160(V) |
|
Electronic Shutter |
Auto/Manual, 1/5 to 1/20,000s |
|
Min. illumination |
Color: 0.005 Lux @ (F1.6, AGC ON) , B/W: 0 Lux with light on |
|
Day & Night |
Auto (ICR) |
|
Wide Dynamic Range |
True WDR |
|
Angle Adjustment |
Pan: 0˚ to 355˚, Tilt: 0˚ to 80˚, Rotation: 0˚ to 360˚ |
|
Lens |
|
Lens Type |
Fixed lens, Fixed focal |
|
Iris |
Fixed Iris |
|
Focal Length |
2.8 mm, 4 mm optional |
|
Max. Aperture |
F1.6 |
|
Field of View (FOV) |
2.8 mm:
- H: 110.5° , V: 56.5°
4 mm:
- H: 88.4° , V: 50° |
|
DORI Distance |
|
Lens |
Detect |
Observe |
Recognize |
Identify |
|
2.8 m |
89.7 m (294.3 ft) |
35.9 m (117.8 ft) |
17.9 m (58.7 ft) |
9 m (29.5 ft) |
|
4 mm |
100 m (328.1 ft) |
40 m (131.2 ft) |
20 m (65.6 ft) |
10 m (32.8 ft) |
|
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. |
|
Illuminator |
|
Illuminator Type |
IR, Warm light |
|
Illumination Distance |
IR distance up to 40 m (131.2 ft)
Warm light distance up to 30 m (98.4 ft) |
|
Illumination On/Off Control |
IR mode, White mode, Intelligent mode, None |
|
IR wavelength |
850 nm |
|
Intelligent Analytics |
|
Multi-Object Detection |
Supports face, human, vehicle detection and capture.
Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
|
Intelligent Analysis |
Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, and Smart motion detection
Support alarm triggering by specified target types (human and vehicle) |
|
People Counting |
Supported |
|
Video and Audio |
|
Streaming Capability |
3 Streams |
|
Stream/Frame Rate |
Stream1: 3840×2160, 2592×1944, 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720 @25/30fps
Stream2: D1, VGA, CIF @25/30fps
Stream3: VGA, CIF, QVGA @25/30fps |
|
Bit Rate Control |
CBR/VBR |
|
Bit Rate |
Stream1: 200 Kbps to 16 Mbps
Stream2: 100 Kbps to 6 Mbps
Stream3: 100 Kbps to 3 Mbps |
|
Smart Encoder |
Supported |
|
Region of Interest (ROI) |
Off/On (8 Zone, Rectangle) |
|
Audio Compression |
G.711 A-law, G.711 μ-law, RAW_PCM |
|
Audio Bit Rate |
64 Kbps (G.711), 128 Kbps (RAW_PCM) |
|
Image |
|
Image Adjustment |
Brightness, Sharpness, Contrast, Saturation adjustable |
|
Scene Mode |
Indoor, Outdoor, Mirror, Corridor mode |
|
Exposure Mode |
Auto, Manual, Shutter priority |
|
White Balance |
Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
|
Day/Night Setting |
Auto, Day, Night, Timer |
|
Noise Reduction |
2D/3D DNR |
|
Image Enhancement |
HLC, BLC, Defog, WDR |
|
Privacy Masking |
4 areas |
|
Event |
|
Alarm Triggers |
IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
|
Event Actions |
Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output, White light alarm output |
|
Network |
|
Protocols |
IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
|
Interoperability |
ONVIF (Profile S/T/G/M), SDK, CGI |
|
Max Concurrent Streams |
10 channels |
|
User/Host Level |
32+ users, 3 levels: Administrator, Operator, Media user |
|
Security |
IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
|
Web Viewer |
<IE11, Chrome, Firefox, Microsoft Edge |
|
Interface |
|
Network Interface |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
|
Built-in Microphone |
Supported |
|
Built-in Speaker |
Supported |
|
Audio Interface |
1ch Input, 1ch Output |
|
Alarm Interface |
1ch Input, 1ch Output |
|
SD Card Slot |
Built-in, up to 1 TB |
|
Reset Button |
Supported |
|
General |
|
Language |
English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
|
Power Supply |
12 VDC (-10% to +25%) / PoE (802.3af) |
|
Power Consumption |
Typical: 3.3 W (12 VDC) / approx. 4.2 W (PoE)
Max (IR on + Speaker): 8.7 W (12 VDC) / approx. 10.9 W (PoE) |
|
Operating Temperature |
-40°C to 60°C (-40°F to 140°F ) |
|
Operating Humidity |
Less than 90% RH |
|
Ingress Protection |
IP66 |
|
Certifications |
CE-EMC
- EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B |
|
Material |
Aluminum alloy body + plastic |
|
Dimensions |
φ140 × 119.2 mm (5.51 × 4.69 inch) |
|
Net Weight |
0.9 kg (1.98 lb) |
