IP Camera Input

16 Channel

Incoming Bandwidth

288 Mbps (160 Mbps with AI enabled)

Outgoing Bandwidth

288 Mbps (160 Mbps with AI enabled)

HDMI Output

3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768

VGA Output

1920 × 1080, 1280 × 1024, 1024 × 768

Different Source Output

Supported

Decoding Capacity

1ch 12MP, 4ch 8MP, 8ch 4MP, 16ch 1080P

Dual Stream

Supported

Multi-screen Display

Default Mode (Mirrored): 1/4/8/9/16

Auxiliary Screen Mode:

- Main Screen: 1/4/8

- Auxiliary Screen: 1/4/8

Face Comparison

Real-time captured and display faces comparison results (stranger, channel, similarity)

Multi-objective

Real-time captured and display vehicle, human body, non-motor vehicle, license plates image

Smart Search

Time, Properties, Pictures, License plate

Trigger Events

Buzzer, Alarm push, Email, Alarm Out, Compare the result simultaneously, etc.

Resolution

12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P,  D1 etc.

Recording Mode

Manual, Schedule (Regular, Continuous), Event

Trigger Events

Motion Detection, Video Loss, Alarm in, IVS

Sync Playback

16/9/4/1

Search Mode

Time /Date, Alarm, Picture grid, Event

Backup Mode

USB Device, Network, eSATA

General Alarm

Motion Detection, Video Loss, Alarm in, Alarm out

Intelligent Analysis

(By Camera)

Smoking Detection, Smoke and Fire Detection, Fire Spot Detection, Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-way, Illegal Parking, People Counting, Smart motion detection, Enter Area, Leave Area, etc.

Abnormal Alarm

Disk Alarm, IP Address Conflict, Network Disconnect

Intelligent Analysis

(By NVR)

16-ch intrusion detection, support the accurate detection of human and vehicle

Event Action

Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Alarm output, Recording

Network Protocol

HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE

Remote Users

8 users

P2P

P2P, Web NAT

Interoperability

ONVIF, SDK, CGI

ANR

Supported

Disk Group

Supported

HDD Interface

2 SATA interfaces, up to 12TB capacity for each disk

Network Interface

2 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port

PoE Interface

16 ports, 10/100Mbps, 802.3af/at, max 128W

eSATA

1 eSATA Interface

HDMI

1

VGA

1

Audio In/Out

1/1

Alarm In/Out

6/2

USB Interface

Front panel: 2 × USB 2.0, Rear panel: 1 × USB 3.0

RS-485 Interface

1

Reset Button

On-board reset button

Power Supply

100 to 240VAC

Power Consumption

< 15 W (without HDD)

Operating Conditions

-10 °C to 50 °C (14 °F to 122 °F)

Storage Conditions

Less than 90% RH

Certifications

CE/FCC

Dimensions

372 × 311.2 × 46.4 mm (14.65 × 12.25 × 1.83 inch)

Net Weight

2.75 kg (6.06 lb) without HDD
