IP Camera Input

32 Channel

HDMI Output

HDMI 1: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768
HDMI 2: 1920 × 1080, 1280 × 1024, 1024 × 768

VGA Output

1920 × 1080, 1280 × 1024, 1024 × 768

Different Source Output

Supported

Multi-screen Display

Default Mode (Mirrored): 1/4/8/9/16/32/36
Auxiliary Screen Mode:
- Main Screen: 1/4/8/9/16
- Auxiliary Screen: 1/4/8/9/16

Decoding Capacity

1ch @ 12MP, 4ch @ 4MP, 9ch @ 1080P, 16ch @ D1, 32ch @ D1

Intelligent Analysis (By NVR)

- Real-time face capture with stranger alarm and similarity comparison
- Real-time human, vehicle, and non-motor vehicle image capture and display
- Real-time license plate recognition with plate result display
- Up to 4-ch intrusion detection with human/vehicle classification

Intelligent Analysis (By Camera)

Intrusion, smart motion, single line crossing, double line crossing, object left, object removed, signal bad loitering, multi-loitering, abnormal speed, wrong way, illegal parking, people counting, fence, enter area, leave area, smoking detection, smoke and flame detection, fire spot detection, etc.

Trigger Event Actions

Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Speaker, Alarm out, Camera alarm out, Event recording

Smart Search

Supported

Recording Resolution

12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P,  D1 etc.

Recording Mode

Manual, Schedule (Regular, Continuous), Event

Dual Stream

Supported

Audio Compression

G.711A, G.711U, PCM

Synchronous Playback

16/9/4/1

Search Mode

Time /Date, Alarm, Picture grid, Event

Playback Control

Play, pause, FF/REW, slow, digital zoom

Backup Mode

USB Device, Network, eSATA, NAS

General Event

Motion Detection, Video Loss, Alarm in, Abnormal alarm, Alarm out

Abnormal Alarm

Disk Alarm, IP Address Conflict, Network Disconnect, Failover alarm

Event Actions

Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Alarm output, Recording

Incoming Bandwidth

320 Mbps

Outgoing Bandwidth

320 Mbps

Protocols

HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Address Filtering, DDNS, IEEE 802.1X, SNMP, 3G/4G, PPPoE

Remote Users

Up to 8 users

P2P

P2P, Web NAT

Interoperability

ONVIF, SDK, CGI

Security

IP Address Filtering, User Access Log, IEEE 802.1X, TLS, Signed Firmware

HDD

4 SATA interfaces

Capacity

Up to 16 TB per disk

ANR

Supported

Disk Group

Supported

RAID

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10

Network Interface

2 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet ports

PoE Interface

16 ports, 10/100Mbps, 802.3af/at, max 140W

eSATA

1 eSATA Interface

HDMI

2

VGA

1

Audio Interface

1 input, 1 output

Alarm Interface

6 inputs, 2 outputs

USB Interface

Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0

RS-232

1

RS-485

1

Reset Button

On-board reset button

Power Supply

100 to 240VAC

Power Consumption

< 15 W (without HDD, PoE disabled)

Operating Conditions

-10 °C to 50 °C (14 °F to 122 °F)

Operating Humidity

Less than 90% RH

Certifications

CE/FCC

Dimensions

440 × 373 × 69.9 mm (17.32 × 14.69 × 2.75 inch)

Net Weight

4.8 kg (10.58 lb) without HDD
