Image Sensor

Dual 1/2.8” Progressive Scan CMOS

Max Resolution

8MP, 4608(H) × 1728(V)

Shutter Speed

1/5 to 1/100,000s

Min Illumination

Color: 0.01 Lux @ (F1.6,AGC ON)
B/W: 0.001 Lux @ (F1.6,AGC ON), 0 Lux with illuminator on

Day & Night

Auto (ICR)

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Fixed-focal lens, Dual lens

Focal Length

2.8 mm

Max. Aperture

F1.6

Field of View (FOV)

H: 180°, V: 63°

Iris

Fixed Iris

Type

IR, Warm light (Smart Dual-light)

IR wavelength

850 nm

Distance

IR distance up to 30 m (98.4 ft)
Warm light distance up to 20 m (65.6 ft)

Control

IR mode, White mode, Intelligent mode, None

AI Multi-Target

- Supports face, human, and vehicle detection & capture
- Supports human and vehicle attribute detection
- Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest
Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, and fight detection.
- Supports accurate target classification (human/vehicle)

People Counting

Supported

Heat Map

Supported

Number of Streams

2 Streams

Resolution

Stream1:
- Splicing mode: 4608×1728,  3072×1152
- Multi-channel mode: 2592×1944, 2592×1520, 1920×1080, 1280×720
Stream2:
- Splicing mode: 1536×576, 960×360
- Multi-channel mode: D1, VGA, CIF, QVGA

Frame Rate

Up to 15fps

Bit Rate Control

CBR/VBR

Bit Rate

Splicing mode:
- Stream1: 500 Kbps to 16 Mbps
- Stream2: 100 Kbps to 8 Mbps
Multi-channel mode:
- Stream1: 200 Kbps to 12 Mbps
- Stream2: 100 Kbps to 6 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off / On (8 Zone, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output, White light alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Built-in Speaker

Supported
- Max sound transmission distance of  60m (196.85ft) (45 to 48 dB)

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +20%) / PoE (802.3af)

Power Consumption

Max 11.5W

Operating Temperature

-30°C to 60°C (-22°F to 140°F )

Operating Humidity

Less than 95% RH

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

227.7 × 110 × 80 mm (8.96 × 4.33 × 3.15 inch)

Net Weight

Approx. 0.82 kg (1.81 lb)

Detect

44 m (144.3 ft)

Observe

17.6 m (57.7 ft)

Recognize

8.8 m (28.9 ft)

Identify

4.4 m (14.4 ft)
