Image Sensor

1/1.7” Progressive Scan CMOS

Max Resolution

12MP, 4000(H) × 3000(V)

Shutter Speed

1/5 to 1/50,000s

Min Illumination

Color: 0.01 Lux @ (F2.4, AGC ON),
B/W: 0.005 Lux @ (F2.4, AGC ON), 0 Lux with IR on

Day & Night

Auto (ICR)

Lens Type

Fixed-focal lens

Focal Length

1.8 mm

Max. Aperture

F2.4

Field of View (FOV)

180° × 180°

Iris

Fixed Iris

Type

IR

IR wavelength

850 nm

Distance

Up to 15 m (49.2 ft)

Control

Auto/ Manual

AI Multi-Target

- Supports face, human, and vehicle detection & capture
- Supports human and vehicle attribute detection
- Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest
Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, running detection, fall detection, and fight detection.
- Supports accurate target classification (human/vehicle)

People Counting

Supported

Heat Map

Supported

Number of Streams

2 Streams

Resolution

Stream1:
One-Channel:
- Fisheye View: 4000×3000, 3000×3000, 2560×2560, 1280×960
- 180° Panorama View: 3000×752, 2560×640, 1920×480, 1280×960
- 360° Panorama View: 4000×2000, 2560×1280, 1920×960, 1280×960
- 4PTZ View: 4000×3000, 2048×1536, 1920×1440, 1280×960
- Fisheye + 3PTZ View: 4000×3000, 2048×1536, 1920×1440, 1280×960
Multi-Channel: 1520×1520, 1280×960, 960×960, 720×720,  640×640
Stream2:
One-Channel:
- Fisheye View: D1, 640×640, 480×480
- 180° Panorama View: 832×208, D1
- 360° Panorama View: 640×640, D1
- 4PTZ View: D1, VGA, QVGA
- Fisheye + 3PTZ View: D1, VGA, QVGA
Multi-Channel:  640×640, D1

Frame Rate

Up to 25fps

Bit Rate Control

CBR/VBR

Bit Rate

One-Channel:
- Stream1: 200 Kbps to 16 Mbps
- Stream2: 100 Kbps to 6 Mbps
Multi-Channel:
- Stream1: 100 Kbps to 12 Mbps
- Stream2: 100 Kbps to 6 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Support (Single-channel and fisheye mode)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Wide Dynamic Range

DWDR

Privacy Masking

Support (Single-channel and fisheye mode)

Mount Type

Ceiling Mount, Wall Mount, Desktop Mount

Decoding Mode

On-board Dewarping/Client-side Dewarping

Display Mode

12 display modes in total
Client-side Dewarping:
- 180° panorama view, 360° panorama view, 360° panorama + PTZ, 360° panorama + 3PTZ, 360° panorama + 6PTZ, 360° panorama + 8PTZ, Fisheye view, Fisheye + 3PTZ, Fisheye + 8PTZ, 4PTZ, 2PTZ, Fisheye + 1PTZ + 360°
On-board Dewarping:
- Fisheye view, Double panorama view, 4PTZ, Single panorama view, Fisheye + 3PTZ

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS(WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in microSD card slot, up to 1 TB
* If needed, we recommend purchasing the memory card with the product so it can be pre-installed during production.

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +20%) / PoE (802.3af)

Power Consumption

Max 9 W

Operating Temperature

-30°C to 60°C (-22°F to 140°F )

Operating Humidity

Less than 95% RH

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy body, bubble: plastic

Dimensions

Φ130.1 × 38.3 mm ( Φ5.12 × 1.51 inch)

Net Weight

Approx. 435 g (0.96 lb)

Detect

34.5 m (113.2 ft)

Observe

13.8 m (45.3 ft)

Recognize

6.9 m (22.6 ft)

Identify

3.45 m (11.3 ft)
