Image Sensor

Vanadium Oxide Uncooled Focal Plane Arrays

1/2.8" STARVIS CMOS

Resolution

Sensor is 400×300, Image can be scaled up to 704×576

2592 (H)×1520 (V), 4MP

Pixel Pitch

17μm

Spectral Range

8 to 14μm

NETD

≤ 40mK

Min. Illumination

Color: 0.07 Lux @(F1.6, AGC ON),

B/W: 0.007 Lux (F1.6, AGC ON)

Shutter Speed

1/5 to 1/100,000s

Lens Type

Fixed lens

30x optical zoom

Focal Length

8 mm, 15 mm, 25 mm, 35 mm, 50 mm

5.3 to 159 mm

Max. Aperture

F1.0

F1.6

Focus Control

Manual focus

Auto/Manual/Semi-automatic

Field of View (FOV)

8 mm, H: 46°, V: 35.3°

15 mm, H: 25.5°, V: 19.2°

25 mm, H: 15.4°, V: 11.6°

35 mm, H: 11°, V: 9°

50 mm, H: 7.7°, V: 5.8°

H: 56.3° to 2.7°, V: 33.3° to 1.5°

AI Multi-Target

Human and Vehicle detection

Face / Human / Vehicle detection and capture

Intelligent Analysis

Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-Way Detection, Enter Area, Leave Area, Smart Motion Detection

Support alarm triggering by specified target types (human and vehicle)

Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-Way Detection, Smart Motion Detection

Support alarm triggering by specified target types (human and vehicle)

Smoke and Flame Detection

Supported

Fire Spot Detection

Supported

People Counting

Supported

Supported

Stream/Frame Rate

Stream1: D1 (704×576) @25/30fps

Stream2: CIF @25/30fps

Stream1: 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720 @25/30fps

Stream2: D1, VGA, CIF @25/30fps

Stream3: VGA, CIF, QVGA @25/30fps

Bit Rate Control

CBR/VBR

CBR/VBR

Bit Rate

Stream1: 100 Kbps to 6 Mbps,

Stream2: 10 Kbps to 1.5 Mbps

Stream1: 200 kbps to 12 Mbps

Stream2: 100 kbps to 6 Mbps

Stream3: 100 kbps to 3 Mbps

Smart Encoder

Supported

Supported

Region of Interest

Off/On (8 Zone, Rectangle)

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Setting

Brightness, Contrast, Sharpness

Brightness, Saturation, Contrast, Sharpness

Mirror

Horizontal / Vertical / Horizontal+Vertical

Horizontal / Vertical / Horizontal+Vertical

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

FFC Control

Auto / Manual

White Balance

Auto / Tungsten / Fluorescent / Daylight / Shadow / Manual

Day/Night

Auto / Day mode / Night mode / Timer

Noise Reduction

2D/3D DNR

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Wide Dynamic Range

True WDR

OSD

Up to 8 OSD

Up to 8 OSD

Privacy Masking

Supported

Supported

Temperature Range

-20°C to 150°C (-4°F to 302°F)

Accuracy

±2°C / ±2%

Temperature Detection

3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line).

Temperature Alarm

Temperature difference alarm, Threshold alarm, Temperature rise alarm

Temperature Display

Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature

Response Time

≤ 30ms

Pan/Tilt Range

Pan: 0° to 360° endless, Tilt: +90° to -90°

Pan/Tilt Speed

Pan: 0.01° to 60°/s, Tilt: 0.01° to 30°/s

Wiper

Supported

Preset Accuracy

± 0.1°

Presets

400

Scan

8 scans

Patrol

12 patrols, up to 32 presets per patrol

Track

6 tracks

3D Positioning

Supported

Speed Setup

Auto/Manual (0-8)

Power Off Memory

Supported

Idle Motion

The time can be set (1-240 minutes), and functions such as preset positions, patrols, scans, and tracks can be run.

Alarm Triggers

IVS, Temperature anomaly, Motion detection, Alarm Input, Disk alarm, Network alarm, Abnormal sound detection

Event Actions

Alarm out, Alarm record, SMTP, FTP upload, Audible alarm

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPOE, RTSP/RTP/RTCP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, 802.1x, SNMP, Multicast

Compatible Integration

ONVIF (Profile S/T/G/M), CGI, SDK

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Audio Interface

2ch input, 2ch output

Alarm Interface

9ch input, 4ch output

RS-485

1

BNC Interface

1 (CVBS output for visible)

SD Card Slot

Built-in, up to 256GB

Reset Button

Built-in

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

DC36V

Power Consumption

Max 80W

Operating Temperature

-40°C to 60°C (-40°F to 140°F)

Operating Humidity

Less than 90% RH

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Ingress Protection

IP66

Material

Metal

Dimensions

282 × 419 × 316 mm (11.1 × 16.5 × 12.44 inch)

Net Weight

16.5 Kg (Contains 25 mm lens) (36.8 lb)

Focal Length

8 mm

15 mm

25 mm

35 mm

50 mm

Detection Distance

(Humans: 1.8×0.5m)

235 m

(771.7 ft)

441 m

(1,446.9 ft)

735 m

(2,411.4 ft)

1,029 m

(3,376.0 ft)

1,471 m

(4,826.1 ft)

Detection Distance

(Vehicles: 4×1.5m)

722 m

(2,368.8 ft)

1,353 m

(4,439 ft)

2,255 m

(7,398.3 ft)

3,157 m

(10,357.6 ft)

4,510 m

(14,796.6 ft)

Recognition Distance

(Humans: 1.8×0.5m)

59 m

(193.6 ft)

110 m

(360.9 ft)

184 m

(603.7 ft)

257 m

(843.2 ft)

368 m

(1,207.4 ft)

Recognition Distance

(Vehicles: 4×1.5m)

180 m

(590.6 ft)

338 m

(1,109 ft)

564 m

(1,850.4 ft)

789 m

(2,588.6 ft)

1,127 m

(3,697.5 ft)

Identification Distance

(Humans: 1.8×0.5m)

29 m

(95.1 ft)

55 m

(180.4 ft)

92 m

(301.8 ft)

129 m

(423.2 ft)

184 m

(603.7 ft)

Identification Range

(Vehicles: 4×1.5m)

90 m

(295.3 ft)

169 m

(554.5 ft)

282 m

(925.2 ft)

395 m

(1,296 ft)

564 m

(1,850.4 ft)

Note: The table is only for reference and the performance may vary according to different environment.

Note: The optimal detection, recognition, and identification distances are calculated according to Johnson’s Criteria.

Detection Range: In order to distinguish an object from the background, the object must be covered by 1.5 or more pixels.

Recognition Range: In order to classify the object (animal, human, vehicle, etc.), the object must be covered by 6 or more pixels.

Identification Range: In order to identify the object and describe it in details, the object must be covered by 12 or more pixels.

Focal Length

8 mm

15 mm

25 mm

35 mm

50 mm

VCA Detection Distance

(Human: 1.8 × 0.5 m)

50 m

(164.0 ft)

92 m

(301.8 ft)

105 m

(344.5 ft)

210 m

(689.0 ft)

284 m

(931.8 ft)

VCA Detection Distance

(Front/Rear of Vehicle: 4×1.5 m)

100 m

(328.1 ft)

120 m

(393.7 ft)

200 m

(656.2 ft)

350 m

(1,148.3 ft)

450 m

(1,476.4 ft)

Temperature Measurement

(Object: 0.2 × 0.2m)

19 m

(62.3 ft)

35 m

(114.8 ft)

59 m

(193.6 ft)

82 m

(269 ft)

118 m

(616.8 ft)

Fire Detection

(Object: 0.2 × 0.2m)

47 m

(154.2 ft)

88 m

(288.7 ft)

147 m

(482.3 ft)

206 m

(675.9 ft)

294 m

(964.6 ft)

Note: The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.

Lens

5.3 to 159 mm

DORI Distance (Detection)

104 to 3,120 m (341.2 to 10,236.2 ft)

DORI Distance (Observe)

41.6 to 1,248 m (136.5 to 4,094.5 ft)

DORI Distance (Recognize)

20.8 to 624 m (68.2 to 2,047.2 ft)

DORI Distance (Identify)

10.4 to 312 m (34.1 to 1,023.6 ft)

Note: DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
