Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto/Manual, 1/30 ~ 1/10,000s |
Min. illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR on |
S/N Ratio | More than 50dB |
OSD Joystick | Supported |
Up the Coax | Supported |
Angle Adjustment | Pan: 0˚ ~ 360˚, Tilt: 0˚ ~ 85˚, Rotation: 0˚ ~ 360˚ |
Language | English, Chinese, Traditional Chinese, Russian, Spanish, French, Polish, Italian, Portuguese, Japanese, Korean. |
Lens | |
Lens Type | Fixed |
Iris | Fixed Iris |
Focal Length | 3.6 mm |
Max. Aperture | F2.0 |
Field of View (FoV) | H: 84.4°, V: 45.5° |
Illuminator | |
Illuminator Type | IR |
2pcs | |
Illumination Distance | Up to 20 m (65.6 ft) |
IR wavelength | 850 nm |
Video | |
Resolution | 8MP (3840×2160) |
Frame Rate | AHD/TVI/CVI: 8MP @ 15fps/12.5fps CVBS: PAL/NTSC |
Video Output | Support AHD/TVI/CVI/CVBS Output |
Day/Night | Auto, Color, B/W, Ext |
OSD Menu | Supported |
Wide Dynamic Range | WDR, OFF/ON |
Gain Control | Auto |
Noise Reduction | 2D/3D DNR, Auto/Manual |
White Balance | Auto |
BLC | Supported |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 4 W (12V DC, IR ON) |
Operating Temperature | -10 °C to 55 °C (14°F to 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | IP66 |
Certifications | CE-EMC: - EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Metal + Plastic |
Dimensions | Φ111 × 95 mm (Φ4.37 × 3.74 inch) |
Net Weight | 0.33 kg (0.73 lb) |
