Video & Audio |
|
|
IP Camera Input |
4 Channel |
|
HDMI Output |
3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768 |
|
VGA Output |
1920 × 1080, 1280 × 1024, 1024 × 768 |
|
Different Source Output |
Supported |
|
Multi-screen Display |
1/4 |
|
Decoding Capacity |
1ch 12MP, 4ch 4K |
|
IVS |
|
|
Intelligent Analysis (By NVR) |
- Supports face comparison and image-based search |
|
Intelligent Analysis (By Camera) |
Intrusion, smart motion, single line crossing, double line crossing, object left, object removed, signal bad loitering, multi-loitering, abnormal speed, wrong way, illegal parking, people counting, fence, enter area, leave area, smoking detection, smoke and flame detection, fire spot detection, etc. |
|
Trigger Event Actions |
Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Speaker, Alarm out, Camera alarm out, Event recording |
|
Smart Search |
Supported |
|
Recording |
|
|
Recording Resolution |
12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
|
Recording Mode |
Manual, Schedule (Regular, Continuous), Event |
|
Dual Stream |
Supported |
|
Audio Compression |
G.711A, G.711U, PCM |
|
Playback & Backup |
|
|
Synchronous Playback |
4/1 |
|
Search Mode |
Time /Date, Alarm, Picture grid, Event |
|
Playback Control |
Play, pause, FF/REW, slow, digital zoom |
|
Backup Mode |
USB Device, Network, eSATA, NAS |
|
Event |
|
|
General Event |
Motion Detection, Video Loss, Alarm in, Abnormal alarm, Alarm out |
|
Abnormal Alarm |
Disk Alarm, IP Address Conflict, Network Disconnect |
|
Event Actions |
Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Alarm output, Recording |
|
Network |
|
|
Incoming Bandwidth |
64 Mbps |
|
Outgoing Bandwidth |
64 Mbps |
|
Protocols |
HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Address Filtering, DDNS, IEEE 802.1X, SNMP, 3G/4G, PPPoE |
|
Remote Users |
Up to 8 users |
|
P2P |
P2P, Web NAT |
|
Interoperability |
ONVIF, SDK, CGI |
|
Security |
IP Address Filtering, User Access Log, IEEE 802.1X, TLS, Signed Firmware, Secure boot |
|
Storage |
|
|
HDD |
1 SATA interfaces |
|
Capacity |
Up to 16 TB per disk |
|
ANR |
Supported |
|
Interface |
|
|
Network Interface |
1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet ports |
|
PoE Interface |
4 ports, 10/100Mbps, 802.3af, max 36W |
|
eSATA |
1 eSATA Interface |
|
HDMI |
1 |
|
VGA |
1 |
|
Audio Interface |
1 input, 1 output |
|
Alarm Interface |
4 inputs, 2 outputs |
|
USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
|
RS-485 |
1 |
|
Reset Button |
On-board reset button |
|
General |
|
|
Power Supply |
48VDC/1.25A |
|
Power Consumption |
< 15 W (without HDD, PoE disabled) |
|
Operating Temperature |
-10 °C to 50 °C (14 °F to 122 °F) |
|
Operating Humidity |
≤ 90% RH (Non-condensing) |
|
Certifications |
CE/FCC |
|
Dimensions |
255 × 235.0 × 45.3 mm (10.04 × 9.25 × 1.78 inch) |
|
Net Weight |
Approx. 1 kg (2.2 lb) without HDD |
