Camera |
|
|
Image Sensor |
1/2.8” Progressive Scan CMOS |
|
Max Resolution |
5MP, 2592(H) × 1944(V) |
|
Shutter Speed |
1/5 to 1/20,000s |
|
Min Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), |
|
Day & Night |
Auto (ICR) |
|
S/N Ratio |
55 dB |
|
Lens |
|
|
Lens Type |
Varifocal lens |
|
Focal Length |
2.7–13.5 mm |
|
Max. Aperture |
F1.4–F2.8 |
|
Field of View (FOV) |
H: 100°–30°, V: 72°–23° |
|
Iris |
P-Iris |
|
Focus Control |
Motorized |
|
Illuminator |
|
|
Type |
IR |
|
IR wavelength |
850 nm |
|
Distance |
Up to 60 m (196.85 ft) |
|
Control |
Auto/Manual |
|
Intelligent Analytics |
|
|
AI Multi-Target Detection |
- Supports face, human, and vehicle detection with snapshot capture |
|
Attribute Analysis |
Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest |
|
Intelligent Analysis |
Intrusion detection, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, fight detection |
|
People Counting |
Supported |
|
Video & Audio |
|
|
Number of Streams |
3 Streams |
|
Resolution |
Stream 1: 2592 × 1944, 2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720 |
|
Frame Rate |
Up to 25/30 fps |
|
Bit Rate Control |
CBR/VBR |
|
Bit Rate |
Stream 1: 200 Kbps to 12 Mbps |
|
Smart Encoding |
Supported |
|
Region of Interest (ROI) |
Off/On (8 Zone, Rectangle) |
|
Audio Compression |
G.711 A-law, G.711 μ-law, RAW_PCM |
|
Audio Bit Rate |
64 Kbps (G.711), 128 Kbps (RAW_PCM) |
|
Image |
|
|
Image Adjustment |
Brightness, Sharpness, Contrast, Saturation adjustable |
|
Scene Mode |
Indoor, Outdoor, Mirror, Corridor mode |
|
Exposure Mode |
Auto, Manual, Shutter priority |
|
White Balance |
Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
|
Day/Night Setting |
Auto, Day, Night, Timer |
|
Noise Reduction |
2D/3D DNR |
|
Image Enhancement |
HLC, BLC, Defog, WDR |
|
Wide Dynamic Range |
True WDR (120 dB) |
|
Privacy Masking |
4 areas |
|
Event |
|
|
Alarm Triggers |
IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
|
Event Actions |
Alarm record, Alarm output, FTP upload, Email notification, Snapshot, Audible alarm output |
|
Network |
|
|
Protocols |
IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
|
Application Programming Interface |
ONVIF (Profile S/T/G/M), SDK, CGI |
|
Max Concurrent Streams |
10 channels |
|
User/Host Level |
32+ users, 3 levels: Administrator, Operator, Media user |
|
Web Viewer |
Chrome, Firefox, Microsoft Edge, IE11 or earlier |
|
Security |
|
|
Secure Boot |
Supported |
|
Firmware Protect |
Encrypted firmware, Signed firmware |
|
User Authentication |
Digest authentication, Brute-force attack protection |
|
Network Authentication |
IEEE 802.1X (EAP-TLS) |
|
Secure Communication |
HTTPS, WSS (WebSocket Secure), SRTP |
|
Access Control |
IP-based access control, Auto logout |
|
Data Protect |
Encryption credentials |
|
Audit |
Access, system, and event log management |
|
Secure Storage |
AES-256 encrypted SD card storage |
|
Supply Chain Security |
SBOM |
|
Hardware Security |
FIPS 140-3 Level 3 certified Secure Element |
|
Interface |
|
|
Network Interface |
1 × RJ45 10/100 Mbps Ethernet port |
|
Audio Interface |
1 input, 1 output |
|
Alarm Interface |
2 inputs, 1 output |
|
RS-485 |
1 × RS-485 |
|
SD Card Slot |
Built-in microSD card slot (up to 1 TB) |
|
Reset Button |
Supported |
|
General |
|
|
Language |
English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
|
Power Supply |
100–240 VAC |
|
Power Consumption |
Max. 25 W |
|
Operating Temperature |
-40 °C to 60 °C (-40 °F to 140 °F) |
|
Operating Humidity |
≤ 95% RH (Non-condensing) |
|
Ingress Protection |
IP66/IP68 |
|
Certifications |
CE, FCC |
|
Material |
SUS316L |
|
Dimensions |
303 × 147.72 × 175.08 mm (11.93 × 5.82 × 6.89 in) |
|
Net Weight |
Approx. 5 kg (11.02 lb) |
|
DORI Distance (EN 62676-4 standard) |
|
|
Detect |
62–215 m (203.41–705.38 ft) |
|
Observe |
24.8–86 m (81.36–282.15 ft) |
|
Recognize |
14.2–43 m (46.59–141.08 ft) |
|
Identify |
6.2–21.5 m (20.34–70.54 ft) |
