Image Sensor

1/1.8” Progressive Scan CMOS

Max Resolution

4 MP (2688 × 1520)

Shutter Speed

1/5 to 1/100,000s

Min Illumination

Color: 0.003 Lux @ (F1.3, AGC ON),
B/W: 0.0008 @ (F1.3, AGC ON), 0 Lux with IR on

Day & Night

Auto (ICR)

S/N Ratio

55 dB

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Motorized varifocal lens

Focal Length

4.1–12.8 mm / 8–32 mm / 10–50 mm (optional)

Max. Aperture

F1.5–F2.5 (4.1–12.8 mm), F1.6 (8–32 mm), F1.3–F1.4 (10–50 mm)

Field of View (FOV)

4.1–12.8 mm: H: 91.4°–35.5°, V: 50.5°–20°
8–32 mm: H: 41.1°–14°, V: 23°–7.9°
10–50 mm: H: 42.5°–11.1°, V: 24.3°–6.3°

Iris

Auto Iris

Focus Control

Motorized focus

Type

IR

IR wavelength

850 nm

Distance

4.1–12.8 mm: up to 70 m (229.7 ft)
8–32 mm: up to 80 m (262.5 ft)
10–50 mm: up to 120 m (393.7 ft)

Control

Auto / Manual

Smart Function

License plate recognition (LPR); Vehicle attribute analysis (type, color, direction)

Vehicle Type

Car, SUV, Van, Minivan, Pickup, Bus, Truck, MPV, Sports Car

Vehicle Color

Blue, Yellow, Black, White, Green, Red, Gray, Brown, Gold, Orange

Vehicle Direction

Front-facing, Rear-facing

Vehicle Speed

Up to 120 km/h

LPR Region Support

Europe, United States, Thailand, Nepal, The United Arab Emirates, Taiwan (China), Vietnam, China, Brazil, Australia, Chile, India, Indonesia, Malaysia, Oman, The Philippines, Saudi Arabia, Singapore, South Africa

White/Black List

Up to 20,000 records

EMMC Storage

Up to 20,000 images

LPR Smart Search

Supported

Intelligent Analysis

Intrusion, smart motion detection, single-line crossing, double-line crossing, wrong-way detection, and illegal parking
- Supports alarm triggering based on specified target type (vehicle)

Number of Streams

3 Streams

Resolution

Stream1: 2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720
Stream2: D1, VGA, CIF
Stream3: VGA, CIF, QVGA

Frame Rate

Up to 50/60 fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream 1: 100 Kbps to 16 Mbps
Stream 2: 100 Kbps to 6 Mbps
Stream 3: 100 Kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Up to 8 zones

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation

Scene Mode

Indoor, Outdoor, LPR, Mirror, Corridor mode

Exposure Mode

Auto, Manual, Shutter priority, Iris priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day mode, Night mode, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog, Anti-shake

Wide Dynamic Range

True WDR (120 dB)

Privacy Masking

Up to 4 configurable zones

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, FTP upload, Email notification, Alarm output, Wiegand output, Audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, and Media user

Web Viewer

Chrome, Firefox, Microsoft Edge, IE11 or earlier

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Brute-force attack protection

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access, system, and event logs

Secure Storage

AES-256 encrypted SD card storage

Supply Chain Security

SBOM

Network Interface

1 × RJ45 10/100 Mbps Ethernet port

Built-in Microphone

Supported

Built-in Speaker

Supported

Audio Interface

1 input (3.5 mm), 1 output (3.5 mm)

Alarm Interface

1 input, 2 outputs

RS-485

1 × RS-485

Wiegand Port

1 × Wiegand (26-bit, SHA-1 26-bit, 34-bit, and NEWG 72-bit)

SD Card Slot

Built-in microSD card slot (up to 1 TB)

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%) / PoE (802.3af)

Power Consumption

Max 13.2 W

Operating Temperature

-40 °C to 60 °C (-40 °F to 140 °F )

Operating Humidity

< 95% RH, non-condensing

Ingress Protection

IP66, IK10

Certifications

CE-EMC: EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy

Dimensions

φ110 × 356.3 mm (φ4.33 × 14.03 inch)

Net Weight

Approx. 1.72 kg (3.79 lb)

Detect

4.1–12.8 mm: 73–177 m (240–581 ft)
8–32 mm: 142–402 m (466–1,320 ft)
10–50 mm: 147–553 m (482–1,814 ft)

Observe

4.1–12.8 mm: 29.2–70.8 m (96–232 ft)
8–32 mm: 56.8–160.8 m (186–528 ft)
10–50 mm: 58.8–221.2 m (193–726 ft)

Recognize

4.1–12.8 mm: 14.6–35.4 m (48–116 ft)
8–32 mm: 28.4–80.4 m (93–264 ft)
10–50 mm: 29.4–110.6 m (96–363 ft)

Identify

4.1–12.8 mm: 7.3–17.7 m (24–58 ft)
8–32 mm: 14.2–40.2 m (47–132 ft)
10–50 mm: 14.7–55.3 m (48–181 ft)
