Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Max. Resolution | 4MP, 2592(H) × 1520(V) |
Shutter Speed | 1/5 to 1/20,000s |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), |
Day & Night | Auto (ICR) |
Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
Lens | |
Lens Type | Varifocal lens, Motorized focal |
Focal Length | 2.7 to 12 mm |
Max. Aperture | F1.6 |
Field of View (FOV) | H: 95.6° to 30.7°, V: 51.4° to 17.2° |
Iris | Auto Iris |
Illuminator | |
Illuminator Type | IR |
IR wavelength | 850 nm |
Illumination Distance | Up to 50 m (164.0 ft) |
Illuminator Control | Auto/Manual |
Intelligent Analytics | |
AI Multi-Target Detection | - Supports face, human, and vehicle detection with snapshot capture |
Intelligent Analysis | Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, and fight detection. |
People Counting | Supported |
Video & Audio | |
Number of Streams | 3 Streams |
Resolution | Stream1: 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720 |
Frame Rate | Up to 25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 Kbps to 12 Mbps |
Smart Encoding | Supported |
Region of Interest (ROI) | Off/On (8 Zone, Rectangle) |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) |
Image | |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Mode | Indoor, Outdoor, Mirror, Corridor mode |
Exposure Mode | Auto, Manual, Shutter priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR |
Wide Dynamic Range | True WDR (120dB) |
Privacy Masking | 4 areas |
Event | |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Event Actions | Alarm record, Alarm output, FTP upload, Email notification, Snapshot, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Application Programming Interface | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Security | |
OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware |
User Authentication | Digest authentication, Brute-force attack protection |
Network Authentication | IEEE 802.1X (EAP-TLS) |
Secure Communication | HTTPS, WSS (WebSocket Secure), SRTP |
Access Control | IP-based access control, Auto logout |
Data Protect | Encryption credentials |
Audit | Access, system, and event log management |
Secure Storage | AES-256 encrypted SD card storage |
Supply Chain Security | SBOM |
Interface | |
Network Interface | 1 × Ethernet (10/100 Base-T), RJ-45 connector |
Built-in Microphone | Supported |
Audio Interface | 1ch Input, 1ch Output |
Alarm Interface | 1ch Input, 1ch Output |
SD Card Slot | Built-in microSD card slot, up to 1 TB |
Reset Button | Supported |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC (-10% to +25%) / PoE (802.3af) |
Power Consumption | Basic: Max 3 W (without light) |
Operating Temperature | -40 °C to 60 °C (-40 °F to 140 °F ) |
Operating Humidity | ≤ 95% RH (Non-condensing) |
Ingress Protection | IP67, IK10 (housing) |
Certifications | CE-EMC |
Material | Aluminum alloy housing; PC components |
Dimensions | 242.6 × 87.7 × 81.7 mm (9.55 × 3.45 × 3.22 inch) |
Net Weight | Approx. 865 g (1.91 lb) |
DORI Distance (EN 62676-4 standard) | |
Detect | 67 to 198 m (219.8 to 649.6 ft) |
Observe | 26.8 to 79.2 m (87.9 to 259.8 ft) |
Recognize | 13.4 to 39.6 m (44.0 to 129.9 ft) |
Identify | 6.7 to 19.8 m (22.0 to 65.0 ft) |
