Image Sensor

VOx uncooled focal plane array

Max Resolution

160 × 120 thermal resolution, upscaled output up to 704 × 576

Pixel Pitch

17 µm

Spectral Range

8–14 μm

NETD

≤ 50 mK

Lens Type

Fixed lens

Focal Length

1.5 mm / 2.1 mm (optional)

Max. Aperture

F1.0

Field of View (FOV)

1.5 mm: H: 114°, V: 82°
2.1 mm: H: 90°, V: 64°

Focus Control

Focus-free

AI Multi-Target Detection

Supports human and vehicle detection

Intelligent Analysis

Intrusion, smart motion detection, single-line crossing, double-line crossing, loitering, wrong-way detection, enter area, leave area, fall detection; supports alarm triggering based on specified target types (human/vehicle)

People Counting

Supported

Smoking Detection

Supported

Fire Spot Detection

Supported

Main Stream

D1 (704 × 576)

Sub Stream

CIF, 256 × 192

Frame Rate

Up to 25/30 fps

Bit Rate Control

CBR/VBR

Bit Rate

Main stream: 100 Kbps to 6 Mbps,
Sub stream: 10 Kbps to 1.5 Mbps

Smart Encoding

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Contrast, Sharpness

Scene Mode

Mirror

Pseudo-color Setting

Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal)

FFC Control

Auto / Manual

Noise Reduction

2D/3D DNR

Privacy Masking

Up to 4 configurable zones

Temperature Range

-20 °C to 150 °C (-4 °F to 302 °F)

Accuracy

±8°C (depending on emissivity, distance, ambient temperature settings, etc.)

Temperature Detection

Supports 3 rule types (spot, line, and area); up to 20 rules, including 1 full-screen rule and 19 spot/line/area rules

Temperature Alarm

Temperature difference alarm, threshold alarm, section alarm, temperature rise alarm

Temperature Display

Lower-left corner display; cursor-based display of maximum, minimum, and average temperature values

Alarm Triggers

IVS, temperature anomaly, motion detection, alarm input, network alarm, disk alarm, and abnormal sound detection

Event Actions

Alarm recording, FTP upload, SMTP email notification, alarm output, red and blue light alarm, and audible alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, and Media user

Web Viewer

Chrome, Firefox, Microsoft Edge, IE11 or earlier

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Brute-force attack protection

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access, system, and event logs

Supply Chain Security

SBOM

Network Interface

1 × RJ45 10/100 Mbps Ethernet port

Built-in Microphone

Supported

Built-in Speaker

Supported

Alarm Interface

1 input, 1 output

RS-485

1 × RS-485

CVBS Output

Supported

SD Card Slot

Built-in microSD card slot (up to 1 TB)

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC / PoE (802.3af)

Power Consumption

Max 4 W

Operating Temperature

-40 °C to 60 °C (-40 °F to 140 °F)

Operating Humidity

≤ 95% RH (Non-condensing)

Ingress Protection

IP66, IK10-rate housing

Certifications

CE-EMC: EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4
FCC: 47 CFR Part 15, Subpart B

Material

Aluminum alloy

Dimensions

φ110 × 91.8 mm (4.33 × 3.61 inch)

Net Weight

Approx. 650 g (1.43 lb)

Thermal Lens

1.5 mm

2.1 mm

Detection (Human: 1.8×0.5 m)

44.1 m (144.7 ft)

61.6 m (202.0 ft)

Detection (Vehicle: 4×1.5 m)

135.4 m (444.1 ft)

189.5 m (621.7 ft)

Recognition (Human: 1.8×0.5 m)

11.0 m (36.1 ft)

15.4 m (50.5 ft)

Recognition (Vehicle: 4×1.5 m)

33.9 m (111.2 ft)

47.4 m (155.6 ft)

Identification (Human: 1.8×0.5 m)

5.5 m (18.0 ft)

7.7 m (25.3 ft)

Identification (Vehicle: 4×1.5 m)

16.9 m (55.4 ft)

23.7 m (77.8 ft)

Note:
Distances are calculated based on Johnson's Criteria.
Detection: Object must be covered by ≥1.5 pixels.
Recognition: Object must be covered by ≥6 pixels.
Identification: Object must be covered by ≥12 pixels.

Lens

1.5 mm

2.1 mm

VCA Detection (Human: 1.8×0.5 m)

45 mm (147.6 ft)

50 m (164.0 ft)

VCA Detection (Front/Rear of Vehicle: 4×1.5 m)

50 mm (164.0 ft)

60 m (196.9 ft)

Temperature Measurement (1 ×1 m)

17.6 m (57.7 ft)

24.7 m (81.0 ft)

Temperature Measurement (0.2×0.2 m)

3.5 m (11.5 ft)

4.9 m (16.1 ft)

Fire Detection (1×1 m)

44 m (144.4 ft)

62 m (203.4 ft)

Fire Detection (0.2×0.2 m)

8.8 m (28.9 ft)

12.4 m (40.7 ft)

Smoking Detection

7 mm (23.0 ft)

13 m (42.7 ft)

Note:
Values are for reference only. Actual detection range may vary with atmospheric conditions, target size, and installation environment.
