Image Sensor

1/2.8” Progressive Scan CMOS

Max. Resolution

2MP, 1920H) × 1080(V)

Electronic Shutter

Auto/Manual, 1/5 to 1/20,000s

Min. illumination

Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0 Lux with light on

Day & Night

IR cut filter

Wide Dynamic Range

True WDR

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Fixed lens, Fixed focal

Iris

Fixed Iris

Focal Length

2.8 mm, 4 mm optional

Max. Aperture

F1.6

Field of View (FOV)

2.8 mm:

- H: 101.5°, V: 50.5°

4 mm:

- H: 80.3°, V: 41°

Lens

Detect

Observe

Recognize

Identify

2.8 mm

44 m (144.4 ft)

17.6 m (57.7 ft)

8.8 m (28.9 ft)

4.4 m (14.4 ft)

4 mm

56.5 m (185.4 ft)

22.6 m (74.1 ft)

11.3 m (37.1 ft)

5.65 m (18.5 ft)

DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.

Illuminator Type

IR, Warm light

Illumination Distance

IR distance up to 40m (131.2 ft)

Warm distance up to 30m (98.4 ft)

Illumination On/Off Control

Auto/Manual

IR wavelength

850 nm

Multi-Object Detection

Supports face, human, vehicle detection and capture

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, and Smart motion detection

Support alarm triggering by specified target types (human and vehicle)

People Counting

Supported

Streaming Capability

3 Streams

Stream/Frame Rate

Stream1: 1920×1080, 1280×720 @25/30fps

Stream2: D1, VGA, 640×360, CIF, QVGA @ 25/30fps

Stream3: VGA, CIF, QVGA @25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 12 Mbps

Stream2: 100 Kbps to 6 Mbps

Stream3: 100 Kbps to 3 Mbps

Smart Encoder

Supported

Region of Interest (ROI)

Off/On (8 Zone, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Setting

Indoor, Outdoor, Mirror, Corridor Mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, SMTP upload, FTP upload, Alarm output, Audible alarm output, Warm light alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Built-in Microphone

Supported

Built-in Speaker

Supported

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in, up to 256GB

Reset Button

Supported

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%)/PoE (802.3af)

Power Consumption

Max 9.5 W

Operating Temperature

-40°C to 55°C (-40°F to 131°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy + plastic

Dimensions

242.6 × 87.7 × 97.2 mm (9.55 × 3.45 × 3.83 inch)

Net Weight

0.9 kg (1.98 lb)
