Image Sensor

1/1.8” Progressive Scan CMOS

Max. Resolution

8MP, 3840(H) × 2160(V)

Electronic Shutter

Auto/Manual, 1/5 to 1/20,000s

Min. illumination

Color: 0.003 Lux @ (F1.3, AGC ON) , 0   Lux with light on

Day & Night

Auto (ICR)

Wide Dynamic Range

True WDR

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚,   Rotation: 0˚ to 360˚

Lens Type

Varifocal lens, Motorized focal

Iris

DC Iris

Focal Length

3.6 to 11 mm

Max. Aperture

F1.3

Field of View (FOV)

H: 113.4°   to 48.9°, V: 59° to 26.6°

Lens

Detect

Observe

Recognize

Identify

Wide (3.6 mm)

85.4 m (280.2 ft)

34.2 m (112.2 ft)

17.1 m (56.1 ft)

8.5 m (27.9 ft)

Tele (11 mm)

184.8 m (606.3   ft)

73.9 m (242.5 ft)

37 m (121.4 ft)

18.5 m (60.7 ft)

DORI (Detect,   Observe, Recognize, and Identify) is a standard system (EN-62676-4) for   defining the ability of a person viewing the video to distinguish persons or   objects within a covered area. The numbers in this table do not reflect   intelligent function distances.

Illuminator Type

IR, Warm light

Illumination Distance

IR distance up to 60 m (196.9 ft)

Warm light distance up to 50 m (164.0 ft)

Illumination On/Off Control

Auto/Manual

Multi-Object Detection

Supports face, human, vehicle detection and   capture

Intelligent Analysis

Intrusion,   Single line crossing, Double line crossing, Loitering, Wrong-way detection,   Illegal parking, and Smart motion detection

Support   alarm triggering by specified target types (human and vehicle)

People Counting

Support

Streaming Capability

3 Streams

Stream/Frame Rate

Stream1: 3840×2160, 2592×1944, 2592×1520,   2560×1440, 2304×1296, 1920×1080, 1280×720 @25/30fps

Stream2: D1, VGA, CIF @25/30fps

Stream3: VGA, CIF, QVGA @25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 16 Mbps

Stream2: 100 Kbps to 6 Mbps

Stream3: 100 Kbps to 3 Mbps

Smart Encoder

Support

Region of Interest (ROI)

Off/On (8 Zone, Rectangle)

Audio Compression

G.711   A-law, G.711 μ-law, RAM PCM

Audio Bit Rate

64 Kbps   (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation   adjustable

Scene Mode

Outdoor, Indoor, Mirror

Exposure Mode

Full metering, Spot metering, Partial metering

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

HLC, BLC, Defog, WDR

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network   alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP   upload, Audible alarm output, White light alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE,   RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP,   802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

User/Host Level

Up to 10 users, 3 levels: Administrator,   Operator, Media user

Security

IP address filter, encrypted HTTPS, Illegal login   lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Built-in Microphone

Support

Built-in Speaker

Support

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in, up to 1 TB

Reset Button

Support

Language

English, Chinese, Polish, Italian, Portuguese,   Spanish, Russian, French, Czech, Hungarian. Default: English

Power Supply

12 VDC (-10% to +25%)/PoE (802.3af)

Power Consumption

Basic: Max 3.4 W (without light), Max 7 W (with   light)

Max. (Focus + WDR + Speaker + Light on): 9.8 W

Operating Temperature

-40°C to 60°C (-40°F to 140°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC (EN 55032:2015+A1:2020, EN IEC   61000-6-3:2021, EN IEC 61000-3-2:2019+A12021, EN 61000-3-3:2013+A2:2021, EN   55035:2017+A11:2020, EN 50130-4:2011+A1:2014)

FCC (FCC 47 CFR 15, Subpart B, ANSI C63.4-2014)

Material

Aluminum alloy + plastic

Dimensions

303 × 100 × 107 mm (11.9 × 3.94 × 4.21 inch)

Net Weight

1.25 kg (2.76 lb.)
