Parameters | |
Applicable Model | With B: SN-CHP86xxCDN, SN-CHP86xxCDR, SN-CHP86xxEBR With P: SN-CHP86xxPAN, SN-IPT86xxPAR |
Material | Stainless steel 316L |
Water Tank | 5L/10L |
Water Spray Form | Atomizing |
Clean Agent | Windshield washer fluid |
Power Supply | Standard: 24 VDC, Optional: 24 VAC/100 V to 240 VAC |
Max Current | 1.2 A (24VDC type) |
Max Flow | 0.45 GPM (1.7 L/min) |
Max Pressure | 130 PSI (0.9 MPa) |
RS-485, By preset | |
Protocol | Pelco-D |
Baud Rate | 9600 |
Device Address | 3 |
Additional Integration | Water pump control |
Mounting Method | Ground-mounted |
Ambient Temperature | -40°C to +60°C |
Relative Humidity | No more than 95% (± 25°C) |
Ingress Protection | IP66 |
Product Dimensions | 400.4 × 236 × 716 mm (15.76 ×9.29 × 28.19 inch) |
Product Weight | 27 kg (59.52 lb) without water |
