General | |
Power Supply | 12 VDC+10 %, 950 mA (startup current), 90 mA (standby) |
Operating Temperature | −10 °C to 55 °C (14 °F to 131 °F) |
Operating Humidity | 0–95% RH (non-condensing) |
Material | Bolt: Stainless Steel Construction |
Dimensions | Lock Body: 204 × 34 × 38 mm (8.03 × 1.34 × 1.50 in) Armature Plate: 90 × 25 × 2 mm (3.54 × 0.98 × 0.07 in) Bolt: 16 × 16 mm (0.63 × 0.63 in) |
Net Weight | 0.7 kg (1.54 lb) |
Lock Type | Fail-safe (unlocked when power is off) |
Induction Distance | < 10 mm (0.39 in) |
Mechanical Life | Up to 500,000 operating cycles |
Holding Force | Up to 800 kg (1,764 lb) |
Suitable Door Types | Wooden, glass, metal, framed, frameless, and hollow frame doors |
