Camera | |
Image Sensor | 1/3” Progressive Scan CMOS |
Electronic Shutter | Auto |
Min. Illumination | Color: 0.02 Lux @ F1.2, AGC ON; 0 Lux with IR on |
S/N Ratio | >48 dB |
Day/Night Setting | Auto / Color / B&W / External |
Exposure Mode | Global / Center / BLC |
Wide Dynamic Range | DWDR |
BLC | Supported |
White Balance | ATW / Manual |
Noise Reduction | 2D DNR |
Image Enhancement | Contrast, Sharpness, Saturation |
Mirror | On / Off |
Flip | On / Off |
OSD Language | 11 languages: English, Simplified Chinese, Traditional Chinese, Russian, Spanish, French, Polish, Italian, Portuguese, Japanese, Korean |
OSD Joystick | Optional |
Up-the-Coax | Supported |
Lens | |
Lens Type | Fixed |
Focal Length | 2.8 mm / 3.6 mm (Optional) |
Max. Aperture | F2.2 |
Iris | Fixed Iris |
Field of View (FOV) | 2.8 mm: H 89.2°, V 48.9° |
Illuminator | |
Illuminator Type | IR |
Illumination Distance | Up to 20 m (65.6 ft) |
IR Wavelength | 850 nm |
Control | Auto / Manual / Off |
Number of Illuminators | 2 |
Video | |
Resolution | 8MP (3840 × 2160) |
Frame Rate | AHD / TVI / CVI: 8MP @ 12.5/15 fps |
Video Output | AHD / TVI / CVI / CVBS, switchable |
Video Standard | PAL / NTSC |
Audio | |
Microphone | Built-in (audio over coax via TVI) |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 4 W (12 VDC, IR on) |
Operating Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
Operating Humidity | <85% RH |
Ingress Protection | IP66 |
Certifications | CE-EMC: EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
Material | Aluminum alloy |
Angle Adjustment | Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
Dimensions | Ø70 × 183.6 mm (Ø2.76 × 7.23 in) |
Net Weight | Approx. 0.29 kg (0.64 lb) |
