Image Sensor

1/1.8” Progressive Scan CMOS

Max Resolution

4MP, 2688(H) × 1520(V)

Shutter Speed

1/5 to 1/50,000s

Min Illumination

Color: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with illuminator on

Day & Night

Fixed filter

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Varifocal lens, Motorized focal

Focal Length

4.5 to 8 mm, and 8 to 32 mm optional

Max. Aperture

F1.0

Field of View (FOV)

4.5 to 8 mm,
- H: 101° to 57.5°, V: 52.7° to 32°
8 to 32 mm,
- H: 39.7° to 16°, V: 22.6° to 9.2°

Iris

Auto Iris

Type

Warm light

Distance

4.5 to 8 mm,
- Up to 40 m (131.2 ft)
8 to 32 mm,
- Up to 60 m (196.9 ft)

Control

Auto/Manual

AI Multi-Target

- Supports face, human, and vehicle detection & capture
- Supports human and vehicle attribute detection
- Supports multiple frame modes: Full Frame, Four-Corner Frame, Mosaic

Attribute Extraction

Human Attributes: Gender, age, glasses, hat, bag, upper clothing color & style, lower clothing color & style, reflective vest
Vehicle Attributes: Type, color, brand, orientation

Intelligent Analysis

Intrusion, smart motion detection, single line crossing, double line crossing, loitering, wrong-way detection, area people limit, perimeter detection, illegal parking, running detection, fall detection, and fight detection.
- Supports accurate target classification (human/vehicle)

People Counting

Supported

Number of Streams

3 Streams

Resolution

Stream1: 2688×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720
Stream2: D1, VGA, CIF
Stream3: VGA, CIF, QVGA

Frame Rate

Up to 25/30fps

Bit Rate Control

CBR/VBR

Bit Rate

Stream1: 200 Kbps to 12 Mbps
Stream2: 100 Kbps to 6 Mbps
Stream3: 100 Kbps to 3 Mbps

Smart Encoding

Supported

Region of Interest (ROI)

Off/On (8 areas, Rectangle)

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Mode

Indoor, Outdoor, Mirror, Corridor Mode

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Wide Dynamic Range

True WDR (120dB)

Privacy Masking

4 areas

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Event Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Snapshot, Audible alarm output, Red and blue light alarm

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Application Programming Interface

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 user levels: Administrator, Operator, Media user

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

OS / Firmware Protect

Encrypted firmware, Signed firmware

User Authentication

Digest authentication, Prevent brute-force attack

Network Authentication

IEEE 802.1X (EAP-TLS)

Secure Communication

HTTPS, WSS (WebSocket Secure), SRTP

Access Control

IP-based access control, Auto logout

Data Protect

Encryption credentials

Audit

Access / System / Event Log management

Secure Storage

SDcard partition encrypt (AES-256), Secure element

Supply Chain Security

SBOM

Network Interface

1 × Ethernet (10/100 Base-T), RJ-45 connector

Built-in Microphone

Supported

Built-in Speaker

Supported

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

SD Card Slot

Built-in microSD card slot, up to 1 TB

Reset Button

Supported

Power Output

12 VDC @ 0.25 A (Supported)

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +25%) / PoE (802.3af)

Power Consumption

Typical: 3.5 W (12VDC); approx. 4.7 W (PoE)
Max (Warm Light + Speaker + Red/Blue Lights on): 9.3 W (12 VDC); approx. 11.6 W (PoE)

Operating Temperature

-40°C to 60°C (-40°F to 140°F )

Operating Humidity

Less than 95% RH

Ingress Protection

IP66

Certifications

CE-EMC
- EN 55032, EN 55035, EN 50130-4, EN IEC 61000-3-2, EN 61000-3-3
FCC 47 CFR Part 15 Subpart B

Material

Aluminum alloy + plastic

Dimensions

303 × 100 × 107 mm (11.9 × 3.94 × 4.21 inch)

Net Weight

Approx. 1.32 kg (2.91 lb)

Detect

4.5 to 8 mm: 69 to 113 m (226.4 to 370.7 ft)
8 to 32 mm: 159 to 370 m (521.7 to 1,213.9ft)

Observe

4.5 to 8 mm: 27.6 to 45.2 m (90.6 to 148.3 ft)
8 to 32 mm: 63.6 to 148 m (208.7 to 485.6ft)

Recognize

4.5 to 8 mm: 13.8 to 22.6 m (45.3 to 74.1 ft)
8 to 32 mm: 31.8 to 74 m (104.3 to 242.8 ft)

Identify

4.5 to 8 mm: 6.9 to 11.3 m (22.6 to 37.1 ft)
8 to 32 mm: 15.9 to 37 m (52.2 to 121.4 ft)
