General | |
System | Linux |
Max Device | 999 |
Decoding | H.265, H.264 |
Resolution | Max 1080P for 1 channel: 1920 x 1080 |
Protocol | Onvif |
Joystick | 4D |
Output | RS422 (Reserved), RS232 (Development port), RJ45 |
Beep | On/off |
Screen | TFT LCD 800*480 |
Environmental | |
Power Supply | 12 VDC /2A, ≤ 5W |
Operating Humidity | 20% ~ 80% RH |
Operating Temperature | -10 °C ~ 55 °C (14 °F ~ 131 °F) |
Dimensions | 297mm (L) x 210mm (W) x 118.7mm (H) |
Net Weight | 890 g |
