Image Sensor | 1/1.8” Progressive Scan CMOS |
Max. Resolution | 2592(H) × 1520(V) |
Min. illumination | Color: 0.001 Lux @ (F1.5, AGC ON), B/W: 0.0005 Lux @ (F1.5, AGC ON), 0 Lux with IR |
Electronic Shutter | Auto/Manual, 1/5 to 1/20,000s |
Day & Night | Auto (ICR) |
Wide Dynamic Range | True WDR |
Focal Length | 6.8 to 251 mm |
Max. Aperture | F1.5 to F4.8 |
Angle of View | H: 60.4° to 2.5°, V: 36.5° to 1.5° |
Optical Zoom | 37x |
Digital Zoom | 16x |
Iris Control | Auto/Manual |
Focus Control | Auto/Manual/Semi-automatic |
Detection | 95 to 3,515 m (311.68 to 11,532.15 ft) |
Observe | 38 to 1,406 m (124.67 to 4,612.86 ft) |
Recognize | 19 to 703 m (62.34 to 2,306.43 ft) |
Identify | 9.5 to 351.5 m (31.17 to 1,153.22 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. | |
Illuminator | |
Illuminator Type | IR + Laser |
Illumination Distance | Up to 500 m (1,640.4 ft) |
Illuminator On/Off Control | Auto/Manual |
IR wavelength | 850 nm |
Intelligent Analytics | |
Multi-Object Detection | Support face, human, vehicle detection and capture Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
Smoke and Flame Detection | Supported |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, and Smart motion detection (support the accurate detection of vehicle and human) |
People Counting | Supported |
Smart Tracking | Supported |
PTZ | |
Pan/Tilt Range | Pan: 0° to 360° endless, Tilt: -10° to +90° (auto-flip) |
Pan Speed | Pan speed: 0.1° to 300°/s, preset speed: 300°/s |
Tilt Speed | Tilt speed: 0.1° to 300°/s, preset speed: 300°/s |
Presets | 400 |
Patrol Scan | |
Power-Off Memory | Supported |
3D Positioning | Supported |
PTZ Status Display | Supported |
Idle Motion | The time can be set (1-240 minutes), and functions such as preset positions, patrols, scans, and tracks can be run. |
Video and Audio | |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 2592×1520, 2304×1296, 1920×1080, 1280×720 @25/30fps Stream2: D1, VGA, CIF @25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 kbps to 16 Mbps Stream2: 100 kbps to 6 Mbps Stream3: 100 kbps to 3 Mbps |
Smart Encoder | Supported |
Region of Interest (ROI) | Supported |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 kbps (G.711), 128 kbps (RAW_PCM) |
Image | |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Mode | Indoor, Outdoor, Mirror |
Exposure Mode | Auto, Manual, Shutter priority, Iris priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR, Anti-shake |
Privacy Masking | Support 40 zones, mask color configurable |
Event | |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Event Actions | Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Security | IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface | |
Network Interface | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
Audio Interface | 1ch Input, 1ch Output |
Alarm Interface | 7ch Input, 2ch Output |
RS-485 | Supported |
BNC Interface | 1 BNC (CVBS output) |
SD Card Slot | Built-in, up to 1 TB |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 24 VAC / 36 VDC / PoE++ (802.3bt), Standard Equipped: 36VDC |
Power Consumption | Less than 45 W |
Operating Temperature | -40°C to 60°C (-40°F to 140 °F) |
Operating Humidity | Less than 90% RH |
Ingress Protection | IP66, IK10 |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 CE-LVD - EN IEC 62368-1 FCC 47 CFR Part 15 Subpart B |
Material | Metal |
Dimensions | φ226.1 × 362.8 mm (φ8.9 × 14.28 inch) |
Net Weight | 5.5 kg (12.13 lb) |
