Camera |
Image Sensor | 1/2.7” Progressive Scan CMOS |
Max. Resolution | 5MP, 2880(H)×1620(V) |
Electronic Shutter | Auto/Manual, 1/5 to 1/20,000s |
Min. illumination | Color: 0.01 Lux @ (F1.6, AGC ON),B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with light |
Day & Night | IR cut filter |
Wide Dynamic Range | True WDR |
Lens |
Focal Length | 2.7 to 13.5mm, 5x optical zoom |
Max. Aperture | F1.66 to F3.03 |
Angle of View | H: 111.5° to 32.3°, V: 57.5° to 17.9° |
Digital Zoom | 16x |
Iris Control | Auto/Manual |
Focus Control | Auto/Manual/Semi-automatic |
DORI Distance |
Detection | 70 to 205 m (229.7 to 672.6 ft) |
Observe | 28 to 82 m (91.9 to 269.0 ft) |
Recognize | 14 to 41 m (45.9 to 134.5 ft) |
Identify | 7 to 20.5 m (23.0 to 67.3 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. |
Illuminator |
Illuminator Type | IR, Warm light |
Illumination Distance | IR distance up to 50 m (164.0 ft) Warm lights distance up to 30 m (98.4 ft) |
Illuminator On/Off Control | Auto/Manual |
IR wavelength | 850 nm |
Intelligent Analytics |
Multi-Object Detection | Support face, human, vehicle detection and capture |
Smoke and Flame Detection | Support |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, and Smart motion detection (support the accurate detection of vehicle and human) |
People Counting | Support |
Smart Tracking | Support |
PTZ |
Pan/Tilt Range | Pan: 0° to 355° endless, Tilt: -20° to +90° (auto-flip) |
Pan Speed | Pan speed: 0.1° to 60°/s, preset speed: 60°/s |
Tilt Speed | Tilt speed: 0.1° to 50°/s, preset speed: 50°/s |
Presets | 400 |
Patrol Scan | 6 Track, 12 Scan, 12 Patrol (up to 32 presets per patrol) |
Power-Off Memory | Support |
3D Positioning | Support |
PTZ Status Display | Support |
Idle Motion | The time can be set (1-240 minutes), and functions such as preset positions, patrols, scans, and tracks can be run. |
Video and Audio |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 2880×1620, 2560×1440, 2304×1296, 1920×1080, 1280×720 @25/30fps Stream2: D1, VGA, 640×360, CIF, QVGA @25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 kbps to 12 Mbps Stream2: 100 kbps to 6 Mbps Stream3: 100 kbps to 3 Mbps |
Smart Encoder | Support |
Region of Interest (ROI) | Support |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 kbps (G.711), 128 kbps (RAW_PCM) |
Image |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Setting | Indoor, Outdoor, Mirror |
Exposure Mode | Auto, Manual, Shutter priority, Iris priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR, Anti-shake |
Privacy Masking | Support 40 zones, mask color configurable |
Event |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Alarm Events | Alarm record, Alarm output, FTP upload, SMTP upload, Linkage tracking, Audible alarm output, White light alarm output, Red and blue alarm output |
Network |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Security | IP address filter, encrypted HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface |
Network Interface | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
Built-in Microphone | Support |
Built-in Speaker | Support, Max sound transmission distance of 60m (196.85ft) (45-48 dB) |
Alarm Interface | 1ch Input, 1ch Output |
SD Card Slot | Built-in, up to 1 TB |
Reset Button | Support |
General |
Language | English, Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian. Default: English |
Power Supply | 12VDC/PoE+ (802.3at) |
Power Consumption | Max. 19.5W (illuminator + red and blue warning light + speaker + PTZ working + glass defogging ) |
Operating Temperature | -30°C to 60°C (-22°F to 140 °F) |
Operating Humidity | Less than 90% RH |
Ingress Protection | IP66 |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 CE-LVD - EN IEC 62368-1 FCC 47 CFR Part 15 Subpart B |
Material | Metal + Plastic |
Dimensions | 174.4 × 138.8 × 270.9 mm (6.87 × 5.46 × 10.67 inch) of wall mount |
Net Weight | 1.28Kg (2.82lb) |
