Camera | |
Image Sensor | 1/2.7” Progressive Scan CMOS |
Max. Resolution | 8MP, 3840(H) × 2160(V) |
Electronic Shutter | Auto/Manual, 1/5 to 1/20,000s |
Min. illumination | Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Day & Night | IR cut filter |
Wide Dynamic Range | True WDR |
Angle Adjustment | Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚ |
Lens | |
Lens Type | Motorized focal |
Iris | Fixed Iris |
Focal Length | 2.7 to 13.5 mm |
Max. Aperture | F1.6 |
Field of View (FOV) | H: 102.8° to 32.6°, V: 54.5° to 18.3° |
DORI Distance | |
Detect | 96 to 272 m (282.2 to 892.4 ft) |
Observe | 38.4 to 108.8 m (126 to 357 ft) |
Recognize | 19.2 to 54.4 m (63 to 178.5 ft) |
Identify | 9.6 to 27.2 m (31.5 to 89.2 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. | |
Illuminator | |
Illuminator Type | IR |
Illumination Distance | Up to 40 m (131.2 ft) |
Illumination On/Off Control | Auto/Manual |
IR wavelength | 850 nm |
Intelligent Analytics | |
Multi-Object Detection | Supports face, human, vehicle detection |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, Illegal parking, and Smart motion detection Support alarm triggering by specified target types (human and vehicle) |
People Counting | Supported |
Video and Audio | |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 3840×2160, 2880×1620, 2592×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720 @25fps Stream2: D1, VGA, CIF @ 25fps Stream3: VGA, CIF, QVGA @ 25fps (Enable WDR is 20fps) |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 Kbps to 16 Mbps Stream2: 100 Kbps to 6 Mbps Stream3: 100 Kbps to 3 Mbps |
Region of Interest | Off/On (8 areas, Rectangle) |
Smart Encode | Supported |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) |
Image | |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Mode | Indoor, Outdoor, Mirror, Corridor mode |
Exposure Mode | Auto, Manual, Shutter priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR |
Privacy Masking | 4 areas |
Event | |
Alarm Triggers | IVS, Motion detection, Alarm input, Disk alarm, Network alarm, Day/Night switch alarm, Abnormal sound detection |
Events Actions | Alarm record, FTP upload, SMTP upload, Alarm output, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Security | IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface | |
Network Interface | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
Audio Interface | 1ch Input, 1ch Output |
Alarm Interface | 1ch Input, 1ch Output |
SD Card Slot | Built-in, up to 1TB |
Reset Button | Supported |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC (-15% to +25%)/PoE (802.3af) |
Power Consumption | Typical: 2.6 W (IR off, 12 VDC) / approx. 3.3 W (PoE) Max: 6.0 W (IR on, 12 VDC) / approx. 7.5 W (PoE) |
Operating Temperature | -30°C to 60°C (-22°F to 140°F ) |
Operating Humidity | Less than 90% RH |
Ingress Protection | IP67 |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Aluminum alloy body |
Dimensions | 232 × 80 × 80 mm (9.13 × 3.15 × 3.15 inch) |
Net Weight | 0.78 kg (1.72 lb) |
