Video Input | |
IP Camera Input | 32 Channel |
Incoming Bandwidth | 320Mbps |
Outgoing Bandwidth | 320Mbps |
Video Output | |
HDMI 1 Output | 3840 × 2160, 1920 × 1080, 1280 × 1024, 1024 × 768 |
HDMI 2 Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
VGA Output | 1920 × 1080, 1280 × 1024, 1024 × 768 |
Different Source Output | Supported |
Decoding Capacity | 4ch 12MP, 8ch 8MP, 16ch 4MP, 32ch 1080P |
Dual Stream | Supported |
Multi-screen Display | Default Mode (Mirrored): 1/4/8/9/16/32/36 Auxiliary Screen Mode: - Main Screen: 1/4/8/9/16 - Auxiliary Screen: 1/4/8/9/16 |
AI Recognition | |
Face Comparison | Real-time captured and display faces comparison results (stranger, channel, similarity) |
Multi-objective | Real-time captured and display vehicle, human body, non-motor vehicle, license plates image |
Smart Search | Time, Properties, Pictures, License plate |
Trigger Events | Buzzer, Alarm push, Email, Alarm Out, Compare the result simultaneously, etc. |
Recoding | |
Resolution | 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1 etc. |
Recording Mode | Manual, Schedule (Regular, Continuous), Event |
Trigger Events | Motion Detection, Video Loss, Alarm in, IVS |
Playback and Backup | |
Sync Playback | 16/9/4/1 |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Backup Mode | USB Device, Network, eSATA |
Alarm | |
General Alarm | Motion Detection, Video Loss, Alarm in, Alarm out |
Intelligent Analysis (By Camera) | Smoking Detection, Smoke and Fire Detection, Fire Spot Detection, Intrusion, Single Line Crossing, Double Line Crossing, Loitering, Wrong-way, Illegal Parking, People Counting, Smart motion detection, Enter Area, Leave Area, etc. |
Abnormal Alarm | Disk Alarm, IP Address Conflict, Network Disconnect |
Intelligent Analysis (By NVR) | 4-ch intrusion detection, support the accurate detection of human and vehicle |
Event Action | Buzzer, Push message to APP, Full screen, Email, FTP, PTZ, Alarm output, Recording |
Network | |
Network Protocol | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, FTP, P2P, IP Filter, DDNS, 802.1X, SNMP, 3G/4G, PPPoE |
Remote Users | 8 users |
P2P | P2P, Web NAT |
Interoperability | ONVIF, SDK, CGI |
Storage | |
ANR | Supported |
Disk Group | Supported |
RAID | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
Interface | |
HDD Interface | 8 SATA interfaces, up to 16TB capacity for each disk |
Network Interface | 2 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port |
eSATA | 1 eSATA Interface |
HDMI | 2 |
VGA | 1 |
Audio In/Out | 1/1 |
Alarm In/Out | 16/6 |
USB Interface | Front panel: 2 × USB 2.0, Rear panel: 2 × USB 3.0 |
RS-485 Interface | 1 |
RS-232 Interface | 1 |
Reset Button | On-board reset button |
General | |
Power Supply | 100 to 240VAC |
Power Consumption | < 15 W (without HDD) |
Operating Conditions | -10 °C to 50 °C (14 °F to 122 °F) |
Storage Conditions | Less than 90% RH |
Certifications | CE/FCC |
Dimensions | 440 × 426 × 111.5 mm (17.32 × 16.77 × 4.39 inch) |
Net Weight | 7.3 kg (16.09 lb) without HDD |
