Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto, PAL: 1/25 ~ 1/10000s, NTSC: 1/30 ~ 1/10000s |
Min. illumination | Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR on |
S/N Ratio | More than 50dB |
OSD Joystick | Supported |
Up the Coax | Supported |
Angle Adjustment | Pan: 0˚ ~ 360˚, Tilt: 0˚ ~ 90˚, Rotation: 0˚ ~ 360˚ |
Lens | |
Lens Type | Fixed |
Iris | Fixed Iris |
Focal Length | 2.8 mm, 3.6 mm optional |
Max. Aperture | F2.0 |
Field of View (FoV) | 2.8 mm: - H: 108.9°, V: 58.8° 3.6 mm: - H: 82.9°, V: 46.6° |
Illuminator | |
Illuminator Type | IR |
24pcs | |
Illumination Distance | Up to 20 m (65.6 ft) |
IR wavelength | 850 nm |
Video | |
Resolution | 1080P (1920×1080) |
Frame Rate | PAL: 25fps ,NTSC: 30fps |
Video Output | Support AHD/TVI/CVI/CVBS Output |
Day/Night | Auto / Color / B&W / EXT |
OSD Menu | Supported |
Wide Dynamic Range | WDR, EXT/OPEN/CLOSE |
Gain Control | Auto |
Noise Reduction | 3D DNR, AUTO/MANUAL (0-30) |
White Balance | Auto |
BLC | Supported |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 5 W (12V DC, IR ON) |
Operating Temperature | -10 °C to 55 °C (14°F to 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | IP67 |
Certifications | CE-EMC: - EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Metal |
Dimensions | 187.6 × 64 × 64 mm (7.39 × 2.52 × 2.52 inch) |
Net Weight | 0.5 kg (1.1 lb) |
