Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto, PAL: 1/25 ~ 1/10000s, NTSC: 1/30 ~ 1/10000s |
Min. illumination | Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0005 Lux @ (F1.2, AGC ON) |
S/N Ratio | More than 50dB |
OSD Joystick | Support |
Up the Coax | Support |
Lens | |
Lens Type | Pinhole lens |
Iris | Fixed Iris |
Focal Length | 3.7 mm |
Max. Aperture | F2.0 |
Field of View (FoV) | H: 78°, V: 40.3° |
Video | |
Resolution | 1080P (1920×1080) |
Frame Rate | PAL: 25fps ,NTSC: 30fps |
Video Output | Support AHD/TVI/CVI/CVBS Output |
Day/Night | Auto / Color / B&W / EXT |
OSD Menu | Support |
Wide Dynamic Range | WDR, EXT/OPEN/CLOSE |
Gain Control | Auto |
Noise Reduction | 3D DNR, AUTO/MANUAL (0-30) |
White Balance | Auto |
BLC | Support |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 2 W (12V DC, IR ON) |
Operating Temperature | -10 °C to 55 °C (14°F to 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | N/A |
Certifications | CE-EMC: - EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Metal |
Dimensions | 46.4 × 57 × 20 mm (Φ4.37 × 3.74 inch) |
Net Weight | 0.11 kg (0.73 lb) |
