Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto, PAL: 1/25 ~ 1/10000s, NTSC: 1/30 ~ 1/10000s |
Min. illumination | Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR on |
S/N Ratio | More than 50dB |
OSD Joystick | Support |
Up the Coax | Support |
Angle Adjustment | Pan: 0˚ ~ 355˚, Tilt: 0˚ ~ 80˚, Rotation: 0˚ ~ 355˚ |
Lens | |
Lens Type | Varifocal lens, motorized focus |
Iris | Fixed Iris |
Focal Length | 2.8 ~ 12 mm |
Max. Aperture | F1.6 |
Field of View (FoV) | H: 94.9° ~ 37.1°, V: H: 50.2° ~ 20.8° |
Illuminator | |
Illuminator Type | IR |
15pcs | |
Illumination Distance | Up to 30 m (98.4 ft) |
IR wavelength | 850 nm |
Video | |
Resolution | 1080P (1920×1080) |
Frame Rate | PAL: 25fps ,NTSC: 30fps |
Video Output | Support AHD/TVI/CVI/CVBS Output |
Day/Night | Auto / Color / B&W / EXT |
OSD Menu | Support |
Wide Dynamic Range | WDR, EXT/OPEN/CLOSE |
Gain Control | Auto |
Noise Reduction | 3D DNR, AUTO/MANUAL (0-30) |
White Balance | Auto |
BLC | Support |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 4.5 W (12V DC, IR ON) |
Operating Temperature | -10 °C to 55 °C (14°F to 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | IP67, IK10 |
Certifications | CE-EMC: - EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Aluminum alloy body, bubble: plastic |
Dimensions | Φ130 × 113.2 mm (φ5.12 × 4.46 inch) |
Net Weight | 0.8 kg (1.76 lb) |
