Camera | |
Image Sensor | 1/2.8” Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto |
Min. illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR on |
S/N Ratio | More than 48dB |
OSD Joystick | Supported |
Up the Coax | Supported |
Angle Adjustment | Pan: 0˚ ~ 355˚, Tilt: 0˚ ~ 80˚, Rotation: 0˚ ~ 355˚ |
Language | English, Chinese, Traditional Chinese, Russian, Spanish, French, Polish, Italian, Portuguese, Japanese, Korean. |
Lens | |
Lens Type | Varifocal lens, motorized focus |
Iris | Fixed Iris |
Focal Length | 2.7 ~ 13.5 mm |
Max. Aperture | F1.6 |
Field of View (FoV) | H: 91.4° to 27.6°, V: 67.9° to 21.1° |
Illuminator | |
Illuminator Type | IR |
15pcs | |
Illumination Distance | Up to 30 m (98.4 ft) |
IR wavelength | 850 nm |
Video | |
Resolution | 5MP (2560×1944) |
Frame Rate | AHD/TVI: 5MP @ 20fps/12.5fps, 4MP @ 25fps/30fps/15fps, CVI: 4MP @ 25fps/30fps, CVBS: PAL/NTSC |
Video Output | Support AHD/TVI/CVI/CVBS Output |
Day/Night | Auto, Color, B/W, Ext |
OSD Menu | Supported |
Wide Dynamic Range | WDR, OFF/ON |
Gain Control | Auto |
Noise Reduction | 2D/3D DNR, Auto/Manual |
White Balance | Auto |
BLC | Supported |
Mirror | Supported |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 4.5 W (12V DC, IR ON) |
Operating Temperature | -10 °C to 55 °C (14°F to 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | IP66, IK10 |
Certifications | CE-EMC: - EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Aluminum alloy body, bubble: plastic |
Dimensions | Φ130 × 113.2 mm (φ5.12 × 4.46 inch) |
Net Weight | 0.67 kg (1.48 lb) |
