Camera | |
Image Sensor | 1/3” Progressive Scan CMOS |
Signal System | PAL/NTSC |
Electronic Shutter | Auto |
Min. illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR on |
S/N Ratio | More than 48dB |
OSD Joystick | Optional |
Up the Coax | Supported |
Angle Adjustment | Pan: 0˚ ~ 360˚, Tilt: 0˚ ~ 90˚, Rotation: 0˚ ~ 360˚ |
Language | English, Chinese, Traditional Chinese, Russian, Spanish, French, Polish, Italian, Portuguese. |
Lens | |
Lens Type | Varifocal lens, Manual focus |
Iris | Fixed Iris |
Focal Length | 2.8 to 12 mm |
Max. Aperture | F1.6 |
Field of View (FoV) | H: 87.2° to 34.3°, V: 51.5° to 19.1° |
Illuminator | |
Illuminator Type | IR |
8 pcs | |
Illumination Distance | Up to 45 m (147.64 ft) |
IR wavelength | 850 nm |
Video | |
Resolution | 2MP (1920×1080) |
Frame Rate | PAL: 25 fps, NTSC: 30 fps |
Video Output | Support AHD/TVI/CVI/CVBS output |
OSD Menu | Supported |
Wide Dynamic Range | DWDR, Close / Open |
AE Setting | Brightness, Exposure Mode (Global / BLC) |
White Balance | Auto / Manual |
Day/Night | Auto / Color / B/W/ Ext |
Image Enhance | Contrast, Sharpness, Saturate |
Noise Reduction | 2D/3D DNR, Auto/Manual (0-10) |
Flip | Close / Open |
Mirror | Close / Open |
General | |
Power Supply | 12 VDC ±10% |
Power Consumption | Max. 6 W (12V DC, IR ON) |
Operating Temperature | -10 °C to 55 °C (14°F to 131 °F) |
Operating Humidity | Less than 85% RH |
Ingress Protection | IP66 |
Certifications | CE-EMC: - EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Metal |
Dimensions | φ78.9 × 232.77 mm (φ3.11 × 9.16 inch) |
Net Weight | 0.43 kg (0.95 lb) |
