Camera |
Image Sensor | 1/3” Progressive Scan CMOS |
Max. Resolution | 4MP, 2560(H) × 1440(V) |
Electronic Shutter | Auto/Manual, 1/5 to 1/20,000s |
Min. illumination | Color: 0.01 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Day & Night | IR cut filter |
Wide Dynamic Range | DWDR |
Angle Adjustment | Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚ |
Lens |
Lens Type | Fixed lens, fixed focal |
Iris | Fixed Iris |
Focal Length | 2.8 mm (4 mm optional) |
Max. Aperture | F2.0 |
Field of View (FOV) | 2.8 mm, - H: 96.4°, V: 53.8° |
DORI Distance |
Lens | Detect | Observe | Recognize | Identify |
2.8 mm | 66 m (216.5 ft) | 26.4 m (86.6 ft) | 13.2 m (43.3 ft) | 6.6 m (21.7 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. |
Illuminator |
Illuminator Type | IR |
Illumination Distance | Up to 30 m (98.4 ft) |
Illumination Control | Auto/Manual |
IR wavelength | 850 nm |
Intelligent Analytics |
Multi-Object Detection | Supports human/vehicle detection. Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, Illegal parking, and Smart motion detection. Support alarm triggering by specified target types (human and vehicle) |
People Counting | Supported |
Video and Audio |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 2560×1440, 2304×1296, 1920×1080, 1280×720 @25/30fps Stream2: D1, VGA, CIF @25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 Kbps to 12 Mbps Stream2: 100 Kbps to 6 Mbps Stream3: 100 Kbps to 3 Mbps |
Region of Interest | Off/On (8 areas, Rectangle) |
Smart Encode | Supported |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) |
Image |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Mode | Indoor, Outdoor, Mirror, Corridor mode |
Exposure Mode | Auto, Manual, Shutter priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR |
Privacy Masking | 4 areas |
Event |
Alarm Triggers | IVS, Motion detection, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Event Actions | Alarm record, FTP upload, SMTP upload |
Network |
Protocols | IPv4/IPv6, RTSP/ RTCP/RTP, TCP/UDP, HTTP/HTTPS, DHCP, DNS, DDNS, PPPoE, UPnP, ICMP, IGMP, FTP, NTP, SMTP, 802.1x, SNMP |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 4 channels |
User/Host Level | Up to 32 users; 3 levels: Administrator, Operator, and Media User |
Security | IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface |
Network Interface | 1 × RJ45 10/100 Mbps Ethernet port |
Built-in Microphone | Supported |
SD Card Slot | Built-in, up to 1 TB |
Reset Button | Supported |
General |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC (-15% to +25%)/PoE (802.3af) |
Power Consumption | Typical: 1.7 W (12 VDC) / approx. 2.2 W (PoE) Max (IR on): 3.5 W (12 VDC) / approx. 4.4 W (PoE) |
Operating Temperature | -25°C to 55°C (-13°F to 131°F ) |
Operating Humidity | Less than 90% RH |
Ingress Protection | IP66 |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Metal |
Dimensions | 179.1 × 68.36 × 68.36 mm (7.05 × 2.69 × 2.69 inch) |
Net Weight | Approx. 0.38 kg (0.84 lb) |
