Image Sensor | 1/2.8” Progressive Scan CMOS |
Max. Resolution | 5MP, 2592H) × 1944(V) |
Shutter Speed | 1/5 to 1/20,000s |
Min. illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR on |
Day & Night | Auto (ICR) |
Angle Adjustment | Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚ |
Lens | |
Lens Type | Varifocal lens |
Iris | Fixed Iris |
Focal Length | 2.7 to 13.5 mm |
Max. Aperture | F1.6 |
Field of View (FOV) | |
Focus Control | Motorized focus |
Detect | 63 to 217 m (206.7 to 711.9 ft) |
Observe | 25.2 to 86.8 m (82.7 to 284.8 ft) |
Recognize | 12.6 to 43.4 m (41.3 to 142.4 ft) |
Identify | 6.3 to 21.7 m (20.7 to 71.2 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. | |
Type | IR |
Distance | Up to 50 m (164.0 ft) |
Control | Auto/Manual |
IR wavelength | 850 nm |
Intelligent Analytics | |
AI Multi-Target | Supports face, human, vehicle detection and capture. Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, and Smart motion detection Support alarm triggering by specified target types (human and vehicle) |
People Counting | Supported |
Video and Audio | |
Number of Streams | 3 Streams |
Resolution | Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720 Stream2: D1, VGA, CIF Stream3: VGA, CIF, QVGA |
Frame Rate | Up to 25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 Kbps to 12 Mbps Stream2: 100 Kbps to 6 Mbps Stream3: 100 Kbps to 3 Mbps |
Smart Encoding | Supported |
Region of Interest (ROI) | Off/On (8 Zone, Rectangle) |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) |
Image | |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Mode | Indoor, Outdoor, Mirror, Corridor mode |
Exposure Mode | Auto, Manual, Shutter priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR |
Wide Dynamic Range | True WDR (120dB) |
Privacy Masking | 4 areas |
Event | |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Event Actions | Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Security | |
OS / Firmware Protect | Encrypted firmware, Secure boot, Signed firmware |
User Authentication | Digest authentication, Prevent brute-force attack |
Network Authentication | IEEE 802.1X (EAP-TLS) |
Secure Communication | HTTPS, WSS (WebSocket Secure), SRTP |
Access Control | IP-based access control, Auto logout |
Data Protect | Encryption credentials |
Audit | Access / System / Event Log management |
Secure Storage | SDcard partition encrypt(AES-256), Secure element |
Supply Chain Security | SBOM |
Interface | |
Network Interface | 1 × Ethernet (10/100 Base-T), RJ-45 connector |
Built-in Microphone | Supported |
Audio Interface | 1ch Input, 1ch Output |
Alarm Interface | 1ch Input, 1ch Output |
SD Card Slot | Built-in microSD card slot, up to 1 TB |
Reset Button | Supported |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC (-10% to +25%)/PoE (802.3af) |
Power Consumption | Basic: Max 3 W (without light) Max. (Focus + WDR + IR on): 7.5 W |
Operating Temperature | -40°C to 60°C (-40°F to 140°F ) |
Operating Humidity | Less than 95% RH |
Ingress Protection | IP67, IK10-rate housing |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Aluminum alloy + Plastic |
Dimensions | 242.6 × 87.7 × 81.7 mm (9.55 × 3.45 × 3.22 inch) |
Net Weight | Approx. 865 g (1.91 lb) |
