Image Sensor

Dual 1/2.8” Progressive Scan CMOS

Max. Resolution

8MP, 4608(H) × 1728(V)

Electronic Shutter

Auto/Manual, 1/5 to 1/100,000s

Min. illumination

Color: 0.01 Lux @ (F1.6,AGC ON)

B/W: 0.001 Lux @ (F1.6,AGC ON), 0 Lux with light on

Day & Night

Auto (ICR)

Angle Adjustment

Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚

Lens Type

Fixed-focal lens, Dual lens: 2.8mm

Iris

Fixed Iris

Focal Length

2.8 mm

F Number

F1.6

Angle of View

H: 180°, V: 63°

Detect

44 m (144.3 ft)

Observe

17.6 m (57.7 ft)

Recognize

8.8 m (28.9 ft)

Identify

4.4 m (14.4 ft)

DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances.

Illuminator Type

2 (IR LED), 2 (Warm Light)

Illumination Distance

IR distance up to 30 m (98.4 ft)

Warm light distance up to 20 m (65.6 ft)

Illumination Control

IR mode, White mode, Intelligent mode, None

IR Wavelength

850 nm

Multi-Object Detection

Supports face, human, vehicle detection and capture.

Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic.

Intelligent Analysis

Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, and Smart motion detection.

Support alarm triggering by specified target types (human and vehicle).

People Counting

Supported

Heat Map

Supported

Streaming Capability

2 Streams

Main Stream

Sub Stream

Bit Rate Control

CBR/VBR

Bit Rate

Smart Encoder

Supported

Region of Interest (ROI)

Supported

Audio Compression

G.711 A-law, G.711 μ-law, RAW_PCM

Audio Bit Rate

64 Kbps (G.711), 128 Kbps (RAW_PCM)

Image Adjustment

Brightness, Sharpness, Contrast, Saturation adjustable

Scene Setting

Indoor, Outdoor

Exposure Mode

Auto, Manual, Shutter priority

White Balance

Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual

Day/Night Setting

Auto, Day, Night, Timer

Noise Reduction

2D/3D DNR

Image Enhancement

WDR, HLC, BLC, Defog

Privacy Masking

Support

Alarm Triggers

IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection

Events Actions

Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output, White light alarm output

Protocols

IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast

Interoperability

ONVIF (Profile S/T/G/M), SDK, CGI

Max Concurrent Streams

10 channels

User/Host Level

32+ users, 3 levels: Administrator, Operator, Media user

Security

IP address filter, HTTPS, Illegal login lock, IEEE 802.1x

Web Viewer

<IE11, Chrome, Firefox, Microsoft Edge

Network Interface

1 Ethernet (10/100 Base-T) RJ-45 Connector

Built-in Microphone

Supported

Built-in Speaker

Max sound transmission distance of  60m (196.85ft) (45 to 48 dB)

Audio Interface

1ch Input, 1ch Output

Alarm Interface

1ch Input, 1ch Output

Reset Button

Supported

SD Card Slot

Built-in, up to 1TB

Language

English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English

Power Supply

12 VDC (-15% to +20%) / PoE (802.3af)

Power Consumption

Max 11.5W

Operating Temperature

-30°C to 60°C (-22°F to 140°F )

Operating Humidity

Less than 90% RH

Ingress Protection

IP66

Certifications

CE-EMC

- EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4

FCC 47 CFR Part 15 Subpart B

Material

Metal

Dimensions

227.7 × 110 × 80 mm (8.96 × 4.33 × 3.15 inch)

Net Weight

0.82 kg (1.81 lb)
