Camera |
Image Sensor | 1/2.7” Progressive Scan CMOS |
Max. Resolution | 5MP, 2880(H) × 1620(V) |
Electronic Shutter | Auto/Manual, 1/5 to 1/20,000s |
Min. illumination | Color: 0.01 Lux @ (F1.6, AGC ON), 0 Lux with light on |
Day & Night | Auto (ICR) |
Wide Dynamic Range | True WDR |
Angle Adjustment | Pan: 0˚ to 360˚, Tilt: 0˚ to 90˚, Rotation: 0˚ to 360˚ |
Lens |
Lens Type | Fixed-focal lens |
Iris | Fixed Iris |
Focal Length | 1.6 mm |
Max. Aperture | F2.0 |
Field of View (FOV) | H: 180°, V: 97° |
DORI Distance |
Detect | 32 m (105.0 ft) |
Observe | 12.8 m (42.0 ft) |
Recognize | 6.4 m (21.0 ft) |
Identify | 3.2 m (10.5 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. |
Illuminator |
Illuminator Type | IR, Warm Light |
Illumination Distance | IR distance up to 25 m (80.02 ft) Warm light distance up to 25 m (80.02 ft) |
Illumination Control | IR mode, White mode, Intelligent mode, None |
IR Wavelength | 850 nm |
Intelligent Analytics |
Multi-Object Detection | Supports face, human, vehicle detection and capture. Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
Intelligent Analysis | Intrusion, Smart motion detection, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Area people limit, Illegal parking, and Perimeter detection. Supports alarm triggering by specified target types (human or vehicle). |
People Counting | Supported |
Heat Map | Supported |
Video and Audio |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 2880×1620, 2304×1296, 1920×1080, 1280×720 @ 25/30fps Stream2: D1, VGA, 640×360, CIF @ 25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 kbps to 12 Mbps Stream2: 100 kbps to 6 Mbps Stream2: 100 kbps to 3 Mbps |
Smart Encoder | Supported |
Region of Interest (ROI) | Supported |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) |
Image |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Setting | Indoor, Outdoor, Mirror, Corridor Mode |
Exposure Mode | Auto, Manual, Shutter priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | WDR, HLC, BLC, Defog |
Privacy Masking | Off / On (4 Areas) |
Event |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Event Actions | Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output, White light alarm output, Red and blue light alarm |
Network |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Security |
OS / Firmware Protect | Encrypted firmware, Signed firmware |
User Authentication | Digest authentication, Prevent brute-force attack |
Network Authentication | IEEE 802.1X(EAP-TLS) |
Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP |
Access Control | IP-based access control, Auto logout |
Data Protect | Encryption credentials |
Audit | Access / System / Event Log management |
Secure Storage | SDcard partition encrypt(AES-256), Secure element |
Supply Chain Security | SBOM |
Interface |
Network Interface | 1 × Ethernet (10/100 Base-T), RJ-45 connector |
Built-in Microphone | Supported |
Built-in Speaker | Supported |
Alarm Interface | 1ch Input, 1ch Output |
SD Card Slot | Built-in microSD card slot, up to 1 TB |
Reset Button | Supported |
General |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC (-15% to +25%) / PoE (802.3af) |
Power Consumption | Typical: 1.8 W (12 VDC) / approx. 2.25 W (PoE) Max (with Light on + Speaker + Red/Blue Lights on): 8.2 W (12 VDC); approx. 10.25 W (PoE) |
Operating Temperature | -30°C to 60°C (-22°F to 140°F ) |
Operating Humidity | Less than 90% RH |
Ingress Protection | IP66 |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Aluminum alloy + Plastic |
Dimensions | Φ110 × 93.9 mm (Φ4.33 × 3.70 inch) |
Net Weight | Approx. 520 g (1.15 lb) |
