Image Sensor | 1/1.7” Progressive Scan CMOS |
Max. Resolution | 12MP, 4000(H) × 3000(V) |
Electronic Shutter | Auto/Manual, 1/5 to 1/50,000s |
Min. illumination | Color: 0.001 Lux @ (F1.2, AGC ON) , B/W: 0.0005 @ (F1.2, AGC ON) |
Day & Night | Auto (ICR) |
Wide Dynamic Range | True WDR |
Lens | |
Lens Mount | C/CS mount |
Iris Type | Fixed Iris, DC-IRIS |
Multi-Object Detection | Supports face, human, vehicle detection and capture. Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Illegal parking, and Smart motion detection Support alarm triggering by specified target types (human and vehicle) |
People Counting | Supported |
Video and Audio | |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 4000×3000, 2592×1944, 1280×960 @25/30fps Stream2: D1, VGA, CIF @25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 Kbps to 16 Mbps Stream2: 100 Kbps to 6 Mbps Stream3: 100 Kbps to 3 Mbps |
Smart Encoder | Supported |
Region of Interest (ROI) | Off/On (8 Zone, Rectangle) |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (RAW_PCM) |
Image | |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Mode | Indoor, Outdoor, Mirror, Corridor mode |
Exposure Mode | Auto, Manual, Shutter priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Time |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR |
Privacy Masking | 4 areas |
Event | |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Events Actions | Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Security | IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface | |
Network Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
Built-in Microphone | Supported |
Audio Interface | 1ch input (line in), 1ch output (line out) |
Alarm Interface | 1ch input, 1ch output |
RS-485 | 1 RS-485 |
BNC Interface | 1ch (CVBS output) |
SD Card Slot | Built-in, up to 1 TB |
Reset Button | Supported |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC / 24 VAC (-10% to +25%) / PoE (802.3af) |
Power Consumption | Typical: 4 W (12 VDC) / approx. 5.8 W (PoE) Max (Focusing): 6.4 W (12 VDC) / approx. 8.2 W (PoE) |
Operating Temperature | -30°C to 60°C (-22°F to 140°F ) |
Operating Humidity | Less than 90% RH |
Ingress Protection | N/A |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-4, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Material | Aluminum alloy |
Dimensions | 152.9 × 74.4 × 69.7 mm (6.02 × 2.93 × 2.74 inch) |
Net Weight | 0.4 kg (0.88 lb) |
