Image Sensor | 1/2.8” Progressive Scan CMOS |
Max. Resolution | 5MP, 2592(H) × 1944(V) |
Min. illumination | Color: 0.07 Lux @ (F1.6, AGC ON), B/W: 0.02 Lux @ (F1.6, AGC ON) |
Electronic Shutter | Auto/Manual, 1/5 to 1/100,000s |
Day & Night | Auto (ICR) |
Wide Dynamic Range | True WDR |
Lens | |
Focal Length | 5.3 to 159 mm, 30x Optical Zoom |
Max. Aperture | F1.6 to F4.3 |
Field of View (FOV) | H: 56.3° to 2.7°, V: 42.4° to 2.0° |
Zoom Speed | Approx. 2.5 s |
Digital Zoom | 16x |
Iris Control | Auto/Manual |
Focus Control | Auto/Manual/Semi-automatic |
DORI Distance | |
Detection | 104 to 3,120 m (341.2 to 10,236.2 ft) |
Observe | 41.6 to 1,248 m (136.5 to 4,094.5 ft) |
Recognize | 20.8 to 624 m (68.2 to 2,047.2 ft) |
Identify | 10.4 to 312 m (34.1 to 1,023.6 ft) |
DORI (Detect, Observe, Recognize, and Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. | |
Intelligent Analytics | |
Multi-Object Detection | Supports face, human, vehicle detection and capture. Supports multiple frame modes: Full Frame, Four-corner Frame, and Mosaic. |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way, Illegal parking, Smart Motion Detection (support the accurate detection of vehicle and human) |
Smoke and Flame Detection | Supported |
People Counting | Supported |
Video and Audio | |
Streaming Capability | 3 Streams |
Stream/Frame Rate | Stream1: 2592×1944, 2592×1520, 1920×1080, 1280×720 @25/30fps Stream2: D1, VGA, CIF @25/30fps Stream3: VGA, CIF, QVGA @25/30fps |
Bit Rate Control | CBR/VBR |
Bit Rate | Stream1: 200 kbps to 12 Mbps Stream2: 100 kbps to 6 Mbps Stream3: 100 kbps to 3 Mbps |
Smart Encoder | Supported |
Region of Interest (ROI) | Supported |
Audio Compression | G.711 A-law, G.711 μ-law, RAW_PCM |
Audio Bit Rate | 64 kbps (G.711), 128 kbps (RAW_PCM) |
Image | |
Image Adjustment | Brightness, Sharpness, Contrast, Saturation adjustable |
Scene Setting | Indoor, Outdoor, Mirror |
Exposure Mode | Auto, Manual, Shutter priority, Iris priority |
White Balance | Auto, Tungsten, Fluorescent, Daylight, Shadow, Manual |
Day/Night Setting | Auto, Day, Night, Timer |
Noise Reduction | 2D/3D DNR |
Image Enhancement | HLC, BLC, Defog, WDR, Anti-shake |
Privacy Masking | Support 8 zones, mask color configurable |
Event | |
Alarm Triggers | IVS, Motion detection, Alarm input, Network alarm, Disk alarm, Day/Night switch alarm, Abnormal sound detection |
Event Actions | Alarm record, SMTP upload, FTP upload, Alarm output, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Security | IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface | |
Network Interface | 1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port |
Audio Interface | 1 input / 1 output |
Alarm Interface | 2 inputs / 1 output |
RS-485 | Supported |
CVBS Output | Optional |
SD Card Slot | Built-in, up to 1 TB * If needed, we recommend purchasing the memory card with the product so it can be pre-installed during production. |
Reset Button | Built-in |
Ambient | |
Ambient temperature | Water cooling: 0°C to 250°C |
Air cooling media | Water Flow: 0.3m³/h, ≤35°C， pressure 0.1 to 0.2MPa |
Ambient pressure | 80Kpa to 106Kpa |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 100 to 240VAC |
Power Consumption | Less than 15 W |
Operating Temperature | -40°C to 60°C (-40°F to 140 °F) |
Operating Humidity | Less than 90% RH |
Ingress Protection | IP68 |
Material | Stainless steel 304 |
Dimensions | 411 × 169 × 188 mm (16.18 × 6.65 × 7.4 inch) |
Net Weight | Approx. 9.1 kg (20.06 lb) |
